Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
115
4.4.4 V-by-One HS output setting items
Level 1
Level 2
Level 3
Setting item
Setting value
V-by-One HS
Output
OFF/ON
Port1 - Port16
Sets ON/OFF for each Port.
0: OFF / 1: ON
Number Of Lanes
Sets the number of data lanes for output from V-by-One HS.
* This is in accordance with the Dotclk Mode setting in “2.1 ALL
OUTPUT”.
0: Auto
Sets the number of data lanes
automatically to match Dot Clock.
20 M to 75 MHz
1 lane
75 M to 150 MHz
2 lanes
150 M to 300 MHz
4 lanes
1: 1 lane
Outputs the same video from output channel
1 and channel 2.
2: 2 lanes
Outputs the same video from output channel
1 and channel 2.
3: 4 lanes
Outputs the same video from output channel
1 and channel 2.
4: 8 lanes
5: 16 lanes
Split
Selects the screen split method of the 4Kx2K mode and x4 mode which use the frame memory in the board.
* This is in accordance with the Split Mode setting in “2.1 ALL OUTPUT”.
When the number of lanes is 8 lanes, the following setting items are displayed.
0: 4 quarter panes output
1: 4 panes vertical output
2: 2 panes horizontal output
3: 2 panes vertical output
4: Without splitting
5: Non Dividing Mode (Mode 0 x4mode)
6: Normal Mode (Mode 1 x4mode)
7: Cross Mode (Mode 2 x4mode)
8: Dividing Normal Mode (Mode 3 x4mode)
9: Dividing Cross Mode (Mode 4 x4mode)
When the number of lanes is 16 lanes, the following setting items are displayed.
0: 4 quarter panes output + 2 panes vertical output
1: 4 panes vertical output + 2 panes vertical output
2: 4 panes horizontal output + 2 panes vertical output
3: 2 panes vertical output + 2 panes vertical output
4: 2 panes vertical output + Without splitting ① (Non Dividing Mode)
5: 2 panes vertical output + Without splitting ② (Normal Mode)
6: 2 panes vertical output + Without splitting ③ (Cross Mode)
7: 2 panes vertical output + With splitting ① (Dividing Normal Mode)
8: 2 panes vertical output + With splitting ② (Dividing Cross Mode)
9: Without splitting
A: * Not output with V-by-One HS.
Pre-Emphasis
Sets pre-emphasis.
0: 0%
1: 100%
3D Flag
Sets the 3D flag.
* “3D flag on DE active period” defined in V-by-One HS Standard
Ver.1.3 and later is supported.
“3D flag on blanking period” is not supported.
0: Disable
1: Enable
Field BET Mode
Sets Field BET Mode.
0: Disable
1: Enable
Control Mode
Sets the control method of HTPDN and LOCKN.
0: Separate
1: 1 -> 234
