Chapter 2 Common Setting Items (ALL OUTPUT)
6
Chapter 2 Common Setting Items (ALL OUTPUT)
This section describes setting items common to all interface units.
The following items show settings common to multiple video and audio output interfaces.
Item
Output interface ON/OFF settings
Synchronization ON/OFF and polarity settings
Level mode settings
Dot clock operation mode (DotClk Mode) settings
Aspect ratio settings
Pattern rendering Color Depth (gradation) settings
RGB/YPbPr selection and color difference coefficient settings
Digital Level settings
2.1 ALL OUTPUT
Common setting item details for each unit are as follows.
Level 1
Level 2
Level 3
Setting item
Setting value
All
Output
Output OFF/ON
Sets output ON/OFF for
each output terminal.
HDMI
[VG-876] Port1 to Port16
0: OFF / 1: ON
[VG-878,878-A] Port1 to Port4
DP
Port1 to Port8
0: OFF / 1: ON
V-by-One HS
Port1 to Port16
0: OFF / 1: ON
SDI
Port1 to Port16
0: OFF / 1: ON
iTMDS
Port1 to Port8
0: OFF / 1: ON
Analog
[VG-876]
VGA1 to 4
YPbPr1 to 4
Composite1 to 4
0: OFF / 1: ON
[VG-878,878-A]
VGA, YPbPr, Composite, Y/C,
SCART
Sync
Sets synchronization signal ON/OFF, and polarity
settings for each output terminal.
HS
Sets output for the HS terminal.
0: OFF No output.
1: Nega Output as
negative polarity.
2: Posi Output as
positive polarity.
VS
Sets output for the VS terminal.
0: OFF No output.
1: Nega Output as
negative polarity.
2: Posi Output as
positive polarity.
CV
Sets Video-On-Syn superimposition
for the analog component signal.
0: OFF / 1: R / 2: G / 3:
RG / 4: B / 5: RB / 6: GB
/ 7: RGB
HDCP
(* In HDMI Output on VG-878,878-A)
Execute Enable
0: Disable / 1: Enable
Port Type (*VG-876 and VG-879
only)
0: HDMI / 1: DP
Port No.
Sets which output port information to
display when displaying the HDCP
pattern.
[VG-876, 879]
(HDMI) 0 to 16
(DP) 0 to 8
[VG-878,878-A]
0: Disable,
1 to 4: HDMI1 to HDMI4
