Chapter 2 Common Setting Items (ALL OUTPUT)
7
Level 1
Level 2
Level 3
Setting item
Setting value
All
Output
HDCP
Auth Version
0: Auto
(* In HDMI Output on VG-878,878-A)
Set the HDCP version.
1: HDCP1.4
Relies on the connection destination
supported version when set to Auto.
2: HDCP2.2
Level Mode
(* In Analog Output and HDMI Output on
VG-878,878-A)
HDMI
0: Full / 1: Limited
DP
0: Full / 1: Limited
SDI
0: Full / 1: Limited
V-by-One HS
0: Full / 1: Limited
iTMDS
0: Full / 1: Limited
Analog
0: Full / 1: Limited
DotClk Mode
● In Auto, single/dual/quad clock modes are
automatically selected according to dot clock.
Screen splitting method is disabled.*
● When Auto is selected on the V-by-One®HS
unit and iTMDS unit, the number of data lanes
automatically switches according to
single/dual/quad clock mode.
0: Auto Operates by automatically selecting the clock mode from
the dot clock.
1: Single Operates as single clock mode.
2: Dual Operates as dual clock mode (double speed).
3: Quad Operates as quad clock mode (quadruple speed).
The following Split Mode setting is displayed when dual clock
mode and quad clock mode are set.
Split Mode
For dual clock mode
Setting unit
MODE0(HDiv)
2 panes horizontal
output
H: 2dot V: 2line
MODE1(VDiv)
2 panes vertical output
H: 4dot V: 1line
MODE2(HDiv)
2 panes horizontal
output
H: 2dot V: 2line
MODE3(VDiv)
2 panes vertical output
H: 4dot V: 1line
MODE4(No Div)
No divisions
H: 4dot V: 1line
MODE5(No Div)
No divisions
H: 4dot V: 1line
MODE6(No Div)
No divisions
H: 4dot V: 1line
MODE7(No Div)
No divisions
H: 4dot V: 1line
MODE8(VDiv)
2 panes vertical output
H: 4dot V: 1line
MODE9(VDiv)
2 panes vertical output
H: 4dot V: 1line
For quad clock mode
Setting unit
MODE0(H2/V2Div)
4 quarter panes
H: 4dot V: 2line
MODE1(V4Div)
4 panes vertical
H: 4dot V: 1line
MODE2(H2/V2Div)
4 quarter panes
H: 4dot V: 2line
MODE3(V4Div)
4 panes vertical
H: 4dot V: 1line
MODE4(V2Div)
2 panes vertical
H: 4dot V: 1line
MODE5(V2Div)
2 panes vertical
H: 4dot V: 1line
MODE6(V2Div)
2 panes vertical
H: 4dot V: 1line
MODE7(V4Div)
4 panes vertical
H: 4dot V: 1line
MODE8(V4Div)
4 panes vertical
H: 4dot V: 1line
MODE9(No Div)
No divisions
H: 4dot V: 1line
MODE10(2SI)
2-sample Interleave
Division
H: 4dot V: 2line
For the V-by-One HS unit and iTMDS unit, it is possible to set more than 4 panes using Split
Mode settings.
