Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
52
4.1.9 HDMI configuration setting items
This section describes configuration settings for the HDMI unit.
Set these settings from MENU > Configuration.
Level 1
Level 2
Level 3
Setting item
Setting value
Configuration
HDMI
Auto Select
Automatically sends the following InfoFrame
value.
0: OFF / 1: ON
・ When Program Data is saved while AutoSelect is ON, the value set via automatic selection is saved.
・ The item indicated by “-” uses the original setting value.
Item
Setting value/reference source
AVI InfoFrame
AFD Pattern displayed
Other than at left
Active Format Information
Valid
-
Active Format Aspect
Follows AFD > Type settings
-
Top Bar
Value calculated from AFD and Timing
-
Bottom Bar
Left Bar
Right Bar
RGB or YCbCr
Follows HDMI > Video Format settings
Picture Aspect
Follows HDMI > AVI InfoFrame > Video Code (EIA/CEA-861compliant)
Repetition
Follows H-Timing> Repetition settings
Audio InfoFrame
Follows Digital Audio> Source settings
Ext.ANALOG to
L-PCM
Int.L-PCM
Ext.I2S L-PCM
(Option)
Ext.ANALOG to DSD
Int.DSD
(Option)
Other
than at
left
Sampling Frequency
-
44.1 kHz
Follows DSD File
information
-
Channel Count
Follows Digital Audio > Output Channel for which the number
of channels are ON
0
1
2 to 8
Refer StreamHeader
2ch
2 to 8ch
-
ACP Packet
Follows ACP Packet> ACP_Type settings
DVD-Audio
Other than at left
DVD-Audio_Type
1
0
Copy_Permission
-
0 (Copy Freely)
Copy_Number
-
0 (1 copies)
Quality
-
0
Transaction
-
0 (Not Present)
