Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
53
Level 1
Level 2
Level 3
Setting item
Setting value
ISRC Packet
Follows ACP Packet> ACP_Type settings
DVD-Audio
Other than at left
OFF/ON ISRC1
-
OFF
ISRC2
Follows ISRC Packet> ISRC_Cont
settings
0
1
OFF
-
OFF
HDMI
Packet Changing
0: Normal Mode
Disable HDMI output
synchronization and change
InfoFrame/Packet.
1: Game Mode
Only changes InfoFrame/Packet
(does not disable
synchronization).
Scramble
Only available for VM-1876-M6,
VM-1876A-M6, VM-1876-M8, VG-878, and
VG-878-A.
*1 is only available for VM-1876-M8, VG-878,
and VG-878-A.
0: Refer Program
Follows output setting item
Scramble settings.
1: OFF
HDMI signal is output without
applying Scramble processing.
2: ON(3.4G over)
A Scramble processed HDMI
signal is output when TMDS
clock 3.4G is exceeded.
3: ON *1
A Scramble processed HDMI
signal is output regardless of the
TMDS clock.
3: Refer EDID *1
Checks EDID and determines
whether or not to apply Scramble
processing.
SCDC Send:
Only available for VM-1876-M6,
VM-1876A-M6, VM-1876-M8, VG-878, and
VG-878-A.
0: ON
Sends SCDC data.
1: OFF
Does not send SCDC data.
2: Refer EDID
References EDID data and
sends SCDC data when
HF-VSDB SCDC_Present=1.
(When HF-VSDB is not present,
and SCDC_Present=0, SCDC
data is not sent.)
HPD Negeate
Only available for VM-1876-M6,
VM-1876A-M6, VM-1876-M8, VG-878, and
VG-878-A.
0: Output OFF
Output is canceled when HotPlug
is Negate.
1: Output ON
Also output when HotPlug is
Negate.
Configuration
