Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
147
《VM-1876-M5》
* Dual clock mode is not supported.
《VM-1876A-M6, VM-1876-M8》
* Quad clock mode is not supported.
Split Mode
*Modes 1 to 9 are
not supported.
DotClk
Mode
Pattern image
Mode0
(4Square)
Quad
Mode10
(2SI)
Multi
VGMode
H2/V2Div
Pattern image
Multi
VGMode
V4Div
CH1 CH2
CH3 CH4
CH1/2/3/4
2-SAMPLE INTERLEAVE
DIVISION
*1 Connector Output：1920ｘ1080 60Hz
2048ｘ1080 60Hz
*1 Connector Output：1920ｘ1080 60Hz
2048ｘ1080 60Hz
Position1 Position2
Position3 Position4
Position1 Position2
Position3 Position4
Split Mode
*Modes 0, 2, and 4
to 9 are not
supported.
DotClk
Mode
Pattern image
Dual
Mode1,3
(VDiv)
Multi
VGMode
H2/V2Div
Pattern image
Multi
VGMode
V4Div
CH1
*1 Connector Output：3840ｘ2160 60Hz
4096ｘ2160 60Hz
(Set any value for VIC.)
Position1 Position2
Position3 Position4
* 1 connector output: 1920 x 1080 60 Hz
2048 x 1080 60 Hz
