Astrodesign VG-876 - Page 22

Chapter 3 Analog Output Settings (ANALOG OUTPUT)
22
Level 1
Level 2
Level 3
Setting item
Setting value
VBI
Function
Paint-on
ROW5
ROW6
ROW7
ROW8
ROW9
ROW10
ROW12, indent
ROW14, indent
Background: Yellow,
semitransparent
Text: Blue
Once the cursor reaches
the 32nd column position on
any row, all subsequent
characters will be displayed
In that column replacing
any previous character.
ABCDEFGHIJKLMNOPQRSTUVWXYZ (S to Y are replaced by Z)
Abcdefghijklmnopqrstuvwxyz (n to y are replaced by z)
T1
--
First Text Service -- T1
Text Mode is a data service,
generally not program related,
which may be transmitted using
either field of line21.
Text Mode data are always
displayed as soon as they are
received and are intended to be
displayed in a manner which
isolates them from the video
program used to transmit
the data. Once the display
window is filled these data are
always scrolled upward through
the display window provided by
the decoder.
T2
--
Second Text Service -- T2
ABCDEFGHIJKLMNOPQRSTUVWXYZ
abcdefghijklmnopqrstuvwxyz
012345678901234567890
!”#$%&'()á+,-./
:;<=>?@[é]íóú
*.–©SM•‟”\
T3
--
Third Text Service -- T3
A Text Mode may be used that
consists of data formatted to
fill a box which in height is
not less than 7 rows and not
more than 15 rows (all of which
should be contiguous), and in
width is not less than
32 columns. Text should be
displayed over a solid
background to isolate it from
the unrelated program video.
Each row of text contains
maximum of 32 characters.
T4
--
Fourth Text Service -- T4
ABCDEFGHIJKLMNOPQRSTUVWXYZ
abcdefghijklmnopqrstuvwxyz
012345678901234567890
!”#$%&'()á+,-./
:;<=>?@[é]íóú
*.–©SM•‟”\
Closed Caption
Interval
0 to 60 [s]
USER Data No.
* Only displayed when
Mode=USER Data is selected.
1 to 20
V-Chip
System
Relies on V-Timing TV Mode
NTSC
0: OFF
NTSC-M
1: MPAA
NTSC-443
2: U.S.TV
PAL-60
3: English
PAL-M
4: French
PAL
PAL-N
PAL-Nc
Other
OFF (fixed)
