Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
33
● Specifications
HDMI
CH1
CH2
CH3
CH4
Connector
HDMI x4
Dot clock
*4
Single clock mode
<For RGB/YCbCr444>
8 bit: 25 to 300 MHz
10 bit: 25 to 240 MHz
12 bit: 25 to 200 MHz
<For YCbCr422>
8 / 10 / 12 bit: 25 to 300 MHz
Dual clock mode
*1
<For RGB/YCbCr444>
8 bit: 50 to 600 MHz
10 bit: 50 to 480 MHz
12 bit: 50 to 400 MHz
<For YCbCr422>
8 / 10 /12 bit: 50 to 600 MHz
<For YCbCr420>
8 bit: 50 to 600 MHz
10 bit: 50 to 480 MHz
12 bit: 50 to 400 MHz
Quad clock mode
*2
<For RGB/YCbCr444>
8 bit: 100 to 1200 MHz
10 bit: 100 to 960 MHz
12 bit: 100 to 800 MHz
<For RGB/YCbCr422>
8 / 10 / 12 bit: 100 to 1200 MHz
No. of colors
RGB 8/10/12 bit each (RGB/ YCbCr444/ YCbCr422/ YCbCr420 (8-bit only
compatible))
Audio
Output
HDMI
L-PCM
Sampling: 32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192 kHz
Output frequency: 100 to 20 kHz
No. of bits: 16 / 20 / 24bit
Compression
AC3, AAC
Option
Next-generation audio compatible*3
DSD, Dolby Digital Plus, Dolby True HD,
DTS HD (High Resolution Audio), DTS HD (Master Audio) etc.
COAX
Sampling: 32k / 44.1k / 48k / 88.2k / 96k / 176.4k / 192 kHz
Copy protect
HDCP Ver2.2 or Ver1.4 (relies on Sink)
Added functions
E-EDID Ver1.4 (DDC2B), xvYCC, CEC
*1 Uses CH1-CH2 (CH3-CH4) for parallel output. However, distributes output for YCbCr420 only.
*2 Uses CH1-CH2-CH3-CH4 for parallel output.
*3 Next-generation audio function is available when a license is purchased.
*4 TMDSCLK 3GHz
