Chapter 4 Digital Output Settings (DIGITAL OUTPUT)
94
[VM-1876-MB]
Level 1
Level 2
Level 3
Setting item
Setting value
Configuration
SDI
Configuration SDI Setting Other
Ancillary Packet
Multiplexes arbitrary ancillary
data specified by the user
with SDI signals.
ANC Packet OFF/ON
0: OFF
Does not insert the ANC
packet.
1: Y ON
Inserts the ANC packet in the Y
stream.
2: C ON
Inserts the ANC packet in the C
stream.
Embed Line1
Specifies the line for multiplexing
the ANC packet.
When '0,' does not multiplex.
0 - VTotal
Embed Sample1
Specifies the sample position for
multiplexing the ANC packet.
When '0,' does not multiplex.
0 - HTotal
Embed Line2
Specifies the line for multiplexing
the ANC packet.
When '0,' does not multiplex.
0 - VTotal
Embed Sample2
Specifies the sample position for
multiplexing the ANC packet.
When '0,' does not multiplex.
0 - HTotal
Parity OFF/ON
0: OFF
Does not automatically
calculate the parity.
1: ON
Automatically calculates the
parity.
DID
Sets the DID data.
Set this with 8 bit/10 bit depending
on the Parity setting.
When Parity = OFF: 10 bit
0 to 0x2FF
When Parity = ON: 8 bit
0 to 0xFF
SDID
Sets the SDID data.
Set this with 8 bit/10 bit depending
on the Parity setting.
DC
Sets the DC data.
Set this with 8 bit/10 bit depending
on the Parity setting.
When '0,' does not multiplex.
UDW[ 1 - UDW 255
Sets the user data word.
Set this with 8 bit/10 bit depending
on the Parity setting.
Enables the data for the number
of DC settings. However, the
maximum is 255.
When '0,' does not multiplex.
CheckSum Calc OFF/ON
0: Manual
Uses a user checksum.
1: Auto
Automatically calculates the
checksum.
