Asus RS700A-E9-RS12 - Page 15

ASUS RS700A-E9 Series
1-5
*Specifications are subject to change without notice.
Model Name RS700A-E9-RS4 RS700A-E9-RS12
Regulatory Compliance
BSMI, CE, FCC (Class A)
Dimension (Depth x Width x
Height)
686 mm x 444 mm x 44 mm (1U)
27” x 17.48” x 1.73”
Net Weight Kg (CPU, DRAM
& storage device not
included)
11.05 Kg 11.35 Kg
Gross Weight Kg (CPU,
DRAM & storage device not
included, packing included)
12.6 Kg 12.9 Kg
Power Supply
(different configuration
by region)
1+1 Redundant 800W 80 PLUS Platinum Power Supply
Rating: 100-127Vac/200-240Vac, 9.4A/4.72A, 47-63Hz Class I or
240Vdc, 4.6A (240Vdc only for China)
Environment
Operating temperature: 10°C ~ 35°C
Non operating temperature: -40°C ~ 60°C
Non operating humidity: 20% ~ 90% (Non condensing)
