Chapter 2: Hardware Information
2-28
2.5.7 Installing Mezzanine cards
To install a Mezzanine card:
2. Firmlyholdtherisercardbracket,
then pull it up to detach it from the
PCIE x16 slot on the motherboard.
3. Remove the screw from the metal
cover(A),thenremovethemetal
cover (B) from chassis.
1. Locate the Mezzanine card connector on your motherboard.
