Chap. I - Gas Analyser
Gas-manual-en.docx — 35 —
25.5 STORAGE AND TRANSPORT
Storage temperature .......................................-10 to 45 °C
The gas analyser must not be transported or stored outdoors where it may be exposed to rain or other inclement
conditions. Areas where it may be exposed to acids, chloride, mercury vapours, etc should be avoided.
26. ASSEMBLY
26.1 GAS ANALYSER
1 pc
Gas Analyser
AT 505 200X
1 pc
AT505 Exhaust sample probe with hose
AT 104 3032
2 pc
Fine filter
6FP 00067
1 pc
Power supply
0AZ 00915
1 pc
Cable of communication AT505/ 1xRS232
AT 505 4033
1 pc
Software CD and User Guide
AT 505 4022 *)
2 pc
O - rings for filter housings
6TG 00158
4 pc
Exhaust probe seal
6HP 00058
1 pc
Condensate drain hose 0.5 m length
*) – Part number may change with new revisions of manual
26.2 GAS ANALYSER ACCESSORIES
1 pc
RPM - Temperature module / A
AT 113 3012
1 pc
Oil temperature sensor 0,65 m / G
AT 103 3014
1 pc
NOx sensor
AT 124 9010
1 pc
IR Remote Control
AT 157 4001
1 pc
Ignition sensor G
AT 102 3030
1 pc
USB to RS232 Converter / GAS
AT 505 4034
1 pc
USB to RS232 Converter / RT
AT 113 4011
Opacimeter ......................................................................................................... AT 605 2000
Multi-Diag Motortester ........................................................................................ AT 550 5000
Multi-Diag Scope ................................................................................................ AT 540 5001
Multi-Diag Handy ................................................................................................ AT 560 5004
27. CALIBRATION AND SERVICE
The analyser should be calibrated at the required interval by a UKAS approved calibration service.
