433MHz Repeater Features and Operation
Digital Life User Manual | Page 44 of 62 ATT-UM-V1.1-201303
433MHz Repeater Features and Operation
The 433MHz Repeater (SW-ATT-RPTR4) is used to “repeat” signals from devices, such
as a smoke detector or a vanishing door/window sensor, when they are too far away
from the DLC-100 to be heard. Typically the repeater is installed at the mid-point
between the DLC-100 and the device(s) that is being repeated.
The 433MHz Repeater (SW-ATT-RPTR4) is equipped with a status green LIGHT on the
front surface of the unit. The green LIGHT blinks dimly and quickly when it detects
433MHz radio traffic that it is not repeating. The green LIGHT blinks brightly and quickly
when it detects 433MHz radio traffic that it is has learned to repeat.
Replacing the 433MHz Repeater (SW-ATT-RPTR4) Batteries
The 433MHz Repeater (SW-ATT-RPTR4) has two (2) non-rechargeable CR123A
Lithium (Panasonic
®
CR123A, Duracell
®
DL123A) batteries that provide twenty-four (24)
hour battery backup.
You can replace the batteries by opening the battery compartment located on the rear of
the unit. You must first remove the retaining screw that is located at the top of the siren
that secures the 433 MHz repeater to the AC outlet and then remove the unit from the
AC outlet.
