Manual, Robotic Tool Changer, QC-5 through QC-27
Document #9610-20-2254-09
Pinnacle Park • 1041 Goodworth Drive • Apex, NC 27539 USA • Tel: 919.772.0115 • Fax: 919.772.8259 • www.ati-ia.com
8
1.3 Safety Precautions
WARNING: Remove all temporary protective materials (caps, plugs, tape, etc.) on
locking face of Tool Changer and modules prior to operation. Failure to do so will
result in damage to Tool Changers, modules, and end-of-arm tooling and could cause
injury to personnel.
WARNING: Do not perform maintenance or repair(s) on the Tool Changer or modules
unless the Tool is safely supported or placed in the tool stand, all energized circuits
(e.g. electrical, air, water, etc.) are turned off, pressurized connections are purged and
power is discharged from circuits in accordance with the customer safety practices and
policies. Injury or equipment damage can occur with the Tool not placed and energized
circuits on. Place the Tool in the tool stand, turn off and discharge all energized circuits,
purge all pressurized connections, and verify all circuits are de-energized before
performing maintenance or repair(s) on the Tool Changer or modules.
WARNING: During operation, the area between the Master and Tool must be kept
clear. Failure to keep area clear will result in damage to Tool Changer, modules, or end-
of-arm tooling and could cause injury to personnel.
WARNING: The Tool Changer is only to be used for intended applications and
applications approved by the manufacturer. Using the Tool Changer in applications
other than intended will result in damage to Tool Changer, modules, or end-of-arm
tooling and could cause injury to personnel.
CAUTION: The Master plate locking mechanism must not be actuated without being
mounted to the interface plate. Damage to the Cover Plate and O-ring may result.
Always attach the Master plate to the Interface plate prior to attempting any operations.
