Printouts from ACTA ACTA 4000 User Guide
106 (136) 2008-12 9836 4171 01
8.6 Tool calibration
TOOL CALIBRATION REPORT 1(1)
Tool identity Date Time
AB735 Jan 28, 2006 07:00:15
CALIBRATION OBJECT Serial Number
Tool B638305
Drive 12434
REFERENCES
ACTA 4000 061005
Transducer 41034
Number Tool Target Difference Difference
(Nm) (Nm) (Nm) (% of MV)
1 20.08 20.08 0.004 0.02
2 20.29 20.08 0.211 1.04
3 20.24 20.11 0.126 0.62
4 20.04 20.00 0.038 0.19
5 19.53 20.08 -0.554 -2.84
6 20.08 20.08 -0.003 -0.01
Torque (Nm) (Nm) (Nm) (%)
MAX 20.29 20.11 0.211 1.04
MIN 19.53 20.00 -0.054 -2.84
MEAN 20.04 20.07 -0.030 -0.15 PASSED
RANGE 0.765 0.110 0.765 3.88
STD 0.272 0.036 0.270 1.37
MEAN TORQUE DIFFERENCE -0.15 % IS WITHIN LIMIT 5%
CALIBRATION TORQUE 59.24 Nm UPDATED: NO
Angle (deg) (deg) (deg) (%)
MAX 207.0 197.0 13.00 6.47
MIN 195.5 188.0 5.500 2.81
MEAN 202.0 192.5 9.500 4.70 PASSED
RANGE 11.50 9.000 7.500 3.65
STD 3.873 3.271 2.470 1.15
MEAN ANGLE DIFFERENCE 4.70 % IS WITHIN LIMIT 5%
COMMENT Tool ok
TEST PERFORMED BY: AJN
