ACTA 4000 User Guide Printouts from ACTA
9836 4171 01 2008-12 111 (136)
8.11 ISO 5393 Calibration report
ISO 5393 REPORT
1(1)
Tool identity Date Time to Date Time
Iso tool 1 Aug 23 2006 10:18.31 Aug 23 2006 10:24.32
Manufacturer:...................... Model:.............................
Manufacturer:...................... Type of tool:......................
High Torque Low
torque
Soft Hard Soft Hard
Total rundowns 25 25 25 25
STIFFNESS (Nm/rev) 11.52 20.1 5.92 17.34
MEAN FROM 0 (deg) 151.2 122.4 193.2 145.3
MEAN (Nm) 15.29 14.88 15.08 15.34
RANGE (Nm) 0.987 1.126 1.124 1.232
SIGMA (Nm) 0.328 0.368 0.346 0.298
MEAN – 3 SIGMA (Nm) 14.31 13.78 14.04 14.45
MEAN + 3 SIGMA (Nm) 16.27 15.98 16.11 16.24
6 SIGMA (Nm) 1.965 2.206 2.076 1.790
6 SIGMA (%) 12.85 14.82 13.77 11.66
COMB. MEAN TORQUE (Nm) 15.03 15.14
MEAN SHIFT (Nm) 0.412 0.268
COMB. TORQUE SCATTER (Nm) 2.497 2.201
COMB. TORQUE SCATTER (%) 16.62 14.54
Torque scatter capability over the whole range (%) 16.62
Tested in accordance with ISO 5393
TEST PERFORMED BY: 6533
.......................................
APPROVED BY: .......................................
