ACTA 4000 User Guide Measuring strategies
9836 4171 01 2008-12 73 (136)
5.2.1 Peak(DD)
The Peak(DD) measure strategy is the default measure strategy and is used to measure the tightening peak
torque for direct driven tools, but can also be used for wrenches. The meaning of the parameters set in the
Prog menu block is shown in the figures below.
Peak, Clutch Tools
Legend:
Number Parameter Number Parameter
1 Cycle start 7 Peak Value
2 Start angle 8 Cycle complete
3 Torque max 9 End time
4 Torque min 10 Angle
5 Angle min 11 End time
6 Angle max
