Measuring strategies ACTA 4000 User Guide
74 (136) 2008-12 9836 4171 01
Peak, clutch tools
When measuring on clutch tools, the clutch noise can cause measurement errors. To avoid such unwanted
effects, the parameter reset time is set as in figure below. During this reset time after cycle complete,
ACTA is inactive and the clutch noise is ignored.
Peak, Clutch Tools
Legend:
Number Parameter Number Parameter
1 Cycle start 7 Peak Value
2 Start angle 8 Cycle complete
3 Torque max 9 Clutch noise
4 Torque min 10 Angle
5 Angle min 11 Reset time
6 Angle max 12 End time
