Atlas Copco ACTA 3000

Technical specifications ACTA 4000 User Guide
126 (136) 2008-12 9836 4171 01
Direct driven Pulse Wrench Click Wrench
Rotation direction
CW CW CW CW
Measure strategy
Peak Peak Peak or Static
installed torque.
Break away
Cycle start
0.05 * TCT 0.05 * TCT 0.05 * TCT 0.05 * TCT
Cycle complete
0.10 * TCT 0.10 * TCT 0.10 * TCT 0.10 * TCT
Start angle
0.12 * TCT 0.12 * TCT 0.12 * TCT 0.12 * TCT
Angle complete
Peak torque Peak torque Peak torque Peak torque
Measure delay time
0 ms 0 ms 0 ms 0 ms
Reset time
0 ms 0 ms 0 ms 0 ms
End time
400 ms 400 ms 400 ms 400 ms
Slip torque1
0.1 Nm 0.1 Nm 0.1 Nm 0.04 * TCT
Batch size
0 0 0 0
Subgroup size
5 5 5 5
Subgroup frequency
1 1 1 1
Batch result
Off Off Off Off
Torque min
0.05 * TCT 0.05 * TCT 0.05 * TCT 0.05 * TCT
Torque max
TCT * TTS TCT * TTS TCT * TTS TCT * TTS
Torque LCLx
-9999.0 -9999.0 -9999.0 -9999.0
Torque UCLx
9999.0 9999.0 9999.0 9999.0
Torque LCLr
0.0 0.0 0.0 0.0
Torque UCLr
9999.0 9999.0 9999.0 9999.0
Torque CM >
0.0 0.0 0.0 0.0
Torque CMK >
0.0 0.0 0.0 0.0
Torque CAM >
0.0 0.0 0.0 0.0
Torque diff % <
9999.0 9999.0 9999.0 9999.0
Angle min
0.0 0.0 0.0 0.0
Angle max
9999.0 9999.0 9999.0 9999.0
Angle LCLx
-9999.0 -9999.0 -9999.0 -9999.0
Angle UCLx
9999.0 9999.0 9999.0 9999.0
Angle LCLr
0.0 0.0 0.0 0.0
Angle UCLr
9999.0 9999.0 9999.0 9999.0
Angle CM >
0.0 0.0 0.0 0.0
Angle CMK >
0.0 0.0 0.0 0.0
Angle CAM >
0.0 0.0 0.0 0.0
Angle diff % <
9999.0 9999.0 9999.0 9999.0
No. of pulses min
0 0 0 0
No. of pulses max
9999 9999 9999 9999
Parameter 1
Torque Torque Torque Torque
1
Not used for direct driven tool.
