- 42 -
If during the WARMING UP SEQUENCE, all
conditions are met to end the WARMING UP
SEQUENCE, but the WARMING UP
SEQUENCE is blocked by the AD
TEMPERATURE CONTROL function, the
following view is shown.
After warming up, the machine is ready to be
loaded and is waiting for a load command.
Active Buttons:
Stop Button
(to initiate Stop command)
Load Button
(to activate Automatic Load)
Measurement View Button
Settings View Button
Alarms View Button
MAIN VIEW
ENGINE WARMING UP
2.7 bar1200RPM1286h
30s
12s
0s
40%
MAIN VIEW
AFTERCOOLER WARMING UP
2.7 bar1200RPM1286h
40%
Active Buttons:
Stop Button
(to initiate Stop command)
Load Button
(to activate Automatic Load)
Measurement View Button
Settings View Button
Alarms View Button
MAIN VIEW
READY TO LOAD
0.0 bar1200RPM1286h
0.0
bar
SET
10.3
bar
40%
