Figure 19-29. V
OH
: I/O Pin Output Voltage vs. Source Current (Low Power Pins, V
CC
= 5V)
Figure 19-30. V
OL
: I/O Pin Output Voltage vs. Sink Current (Low Power Pins, V
CC
= 1.8V)
I/O PIN OUTPUT VOLTAGE vs. SOURCE CURRENT
LOW POWER PINS, V
CC
= 5V
85 °C
25 °C
-40 °C
4
4.2
4.4
4.6
4.8
5
5.2
0 2 4 6 8 101214161820
I
OH
(mA)
V
OH
(V)
I/O PIN OUTPUT VOLTAGE vs. SINK CURRENT
LOW POWER PINS, V
CC
= 1.8V
85 °C
25 °C
-40 °C
0
0.5
1
1.5
2
2.5
3
0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5
I
OL
(mA)
V
OL
(V)
