Atmel ATtiny13A

142
8126F–AVR–05/12
ATtiny13A
Figure 19-35. V
OH
: I/O Pin Output Voltage vs. Source Current (V
CC
= 5V)
Figure 19-36. V
OL
: I/O Pin Output Voltage vs. Sink Current (V
CC
= 1.8V)
85 °C
25 °C
-40 °C
I/O PIN OUTPUT VOLTAGE vs. SOURCE CURRENT
V
CC
= 5V
4
4.2
4.4
4.6
4.8
5
5.2
0 2 4 6 8 10 12 14 16 18 20
I
OH
(mA)
V
OH
(V)
I/O PIN OUTPUT VOLTAGE vs. SINK CURRENT
V
CC
= 1.8V
85 °C
25 °C
-40 °C
0
0.05
0.1
0.15
0.2
0.25
0.3
0.35
0.4
0.45
0.5
0123456
I
OL
(mA)
V
OL
(V)
