Atmel ATtiny13A User Manual

48
8126F–AVR–05/12
ATtiny13A
9.3.3 GIFR – General Interrupt Flag Register
• Bits 7, 4:0 – Res: Reserved Bits
These bits are reserved bits in the ATtiny13A and will always read as zero.
• Bit 6 – INTF0: External Interrupt Flag 0
When an edge or logic change on the INT0 pin triggers an interrupt request, INTF0 becomes set
(one). If the I-bit in SREG and the INT0 bit in GIMSK are set (one), the MCU will jump to the cor-
responding Interrupt Vector. The flag is cleared when the interrupt routine is executed.
Alternatively, the flag can be cleared by writing a logical one to it. This flag is always cleared
when INT0 is configured as a level interrupt.
• Bit 5 – PCIF: Pin Change Interrupt Flag
When a logic change on any PCINT[5:0] pin triggers an interrupt request, PCIF becomes set
(one). If the I-bit in SREG and the PCIE bit in GIMSK are set (one), the MCU will jump to the cor-
responding Interrupt Vector. The flag is cleared when the interrupt routine is executed.
Alternatively, the flag can be cleared by writing a logical one to it.
9.3.4 PCMSK – Pin Change Mask Register
• Bits 7:6 – Res: Reserved Bits
These bits are reserved bits in the ATtiny13A and will always read as zero.
• Bits 5:0 – PCINT[5:0]: Pin Change Enable Mask 5:0
Each PCINT[5:0] bit selects whether pin change interrupt is enabled on the corresponding I/O
pin. If PCINT[5:0] is set and the PCIE bit in GIMSK is set, pin change interrupt is enabled on the
corresponding I/O pin. If PCINT[5:0] is cleared, pin change interrupt on the corresponding I/O
pin is disabled.
Bit 76543210
0x3A –INTF0PCIF–––––GIFR
Read/WriteRR/WR/WRRRRR
Initial Value00000000
Bit 76543210
0x15 – – PCINT5 PCINT4 PCINT3 PCINT2 PCINT1 PCINT0 PCMSK
Read/Write R R R/W R/W R/W R/W R/W R/W
Initial Value00000000
