Atomos NinjaV User Manual

Contents Safety Instructions
User Manual Conventions
The Ninja V is designed to a high standard but there are some things you
should be aware of to prolong the life of the unit and for your own safety.
Using the Ninja V safely
Although the Ninja V is very lightweight compared to all the devices it
replaces, it is still a solid object that could cause injury if misused.
• Always make sure that the Ninja V is mounted securely and is unable
to fall onto anyone nearby. This is especially important when there are
children present who might be tempted to pull on cables.
• Always ensure that cables that run to the Ninja V are clearly visible and
do not present a trip hazard.
• Do not place on uneven or unstable surfaces.
• Do not insert anything but a Ninja V Master Caddy II or AtomX SSDmini
in the drive slot on the rear of the Ninja V.
• Do not touch the Ninja V screen with sharp, metallic or abrasive objects.
• Donotexposetostrongelectricalormagneticelds.
• Do not expose to liquids, rain or moisture.
• Do not dispose of the Ninja V in municipal waste and do not incinerate it,
always follow local regulations for safe disposal.
Care of disk drives
Spinning disks and SSDs are very sensitive to damage from static electricity.
Please observe all the usual electrostatic discharge (ESD) precautions
when handling them.
Please see the section on mechanical shock and vibration later in this
manual for information about how to handle and care for your disk drives.
HDMI cables
Please remember that almost all HDMI cables do not use locking
connectors and will simply pull out if they are jerked or tripped over. Please
ensureyourcablesmakeasecureconnectionandavoidexingthem
excessively to maintain reliability.
To keep things simple but clear, we’ve only adopted two conventions
in this manual:
A helpful tip, suggestion or something to note
because it’s not obvious at rst.
An important note or warning
Warranty & Conditions 1
Introduction 2
1. What’s included 3
2. What you also need 4
Media (HDD/SSD) 4
HDMI Cables 5
Standard 1/4” or 3/8” mount 5
3. Mounting disks in the Master Caddy II 6
4. Connecting and powering up 7
Power ON/Power OFF 7
5. Ninja V connections 9
6. AtomX SSDmini, Master Caddy II and Screw Mounts 10
Master Caddy II / SSDmini / Mounting options 11
7. Using the Ninja V 11
AtomOS10 11
Best Practice 11
- Format Media 13
- Unit Name 13
- File naming 13
- Screen Lock 13
- Firmware updates 14
Main Screen - Home 15
Main Screen - Information Bar 16
Home Screen / Menu functions 17
Home Screen and Menu Functions 18
Information Bar 19
Output / Record 20
File / Meters 21
Audio / Media / Timecode 22
Date and Time 23
Battery / Info 24
8. Monitoring & Recording 25
Setting up for recording 25
SmartControl 25
Monitor Features 26
Using Waveform Monitoring Tools 27
Luma Overlay / RGB Parade / Vectorscope 27
Using Monitor Assist 28
Focus Assist / Zebra / False Color 28
Blue Only / Zoom / Grid Lines / Focus Assist Settings 29
LUTs 30
Monitor 31
- Using Standards – Native / Rec709 / HLG / PQ 31
- Understanding HDR and Log 32
Display 33
File Recovery 33
9. Playback & Playout 34
Playback Mode 35
Playlists 35
Video Format 36
10. Edit 37
SmartLog / Export XML 38
11. HD Pulldown 40
12. Connecting and Editing 41
Connect to Input 41
NLE Support 41
exFAT compatibility 41
  Transferringles 41
Importing / Import into Final Cut Pro X 42
13. Technical Specications 44
14. Optional Accessories 45

Atomos NinjaV Specifications

General

Brand	Atomos
Model	NinjaV
Category	Monitor
Language	English
