Atomos NinjaV User Manual

Weight and Dimensions
Without batteries & media
360g / 12.7oz
With batteries & media
-
Dimensions (W x H x D mm)
151 x 91.5 x 31.5mm
Construction
Aluminium alloy chassis
with ABS Polycarbonate back plate
Mounting points
Anti-rotational 3/8-16 screw mount points, 1/4-20 screw mount
adaptor installed. 1x top and 1x bottom.
Power
Operating power
10-22W
Compatible batteries
Atomos NP-F series and supporting accessories
Input voltage (battery)
6.2V to 16.8V
Battery time (based on 7.4V)
5200mAh - up to 2hrs (monitor & record 4K 60p)
7800mAh - up to 3hrs (monitor & record 4K 60p)
DC In
-
Continuous power
* Patent pending
Continuous power with external adaptor*
Touchscreen
Size
5.2"
Resolution / PPI
1920 x 1080 / 423ppi
Aspect ratio
16:9 native
Color Gamut
REC709 HDTV
Look up table (LUT) support
3D LUT (.cube format)
Anamorphic de-squeeze
2x, 1.5x, 1.33x, Panasonic 4:3
*Support for 2 x 4:3 4k 50/60p in future rmware update
Technology
SuperAtom IPS panel (capacitive touch), calibration to Rec.709
with optional calibration unit
HDR
AtomHDR
Yes
HDR Monitoring/Recording (Gamma)
Sony SLog / SLog2 / SLog3
Canon CLog / CLog2 / Clog3
ARRI Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320 /
LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 /
LogCEI1000 / LogCEI1280 / LogCEI1600
Panasonic Vlog
JVC JLog1
RED Log3G10 / RED LogFilm
FujiFilm F-log
Nikon N-Log
PQ10k
HLG
HDR Monitoring/Recording (Gamut)
Sony SGamut / SGamut3 / SGamut3.cine
Canon Cinema / DCI P3 / DCI P3+
Nikon Bt2020
Panasonic V Gamut
Arri Alexa Wide Gamut
Rec709 / BT.2020
JVC
RED WideGamut / RED DragonColor / DragonColor2 /
RED Color2 / RED Color3 / RED Color4 /
Bit depth
10-bit (8+2 FRC)
Brightness
1000nit (+/- 10%)
HDR input (PQ/HLG)
Yes
HDR output (PQ/HLG)
Yes
Video Input
HDMI
1 x HDMI (2.0)
SDI
-
Signal
Uncompressed true 10-bit or 8-bit 422
(camera dependent)
Video Output (Play Out)
HDMI
1 x HDMI (2.0)
SDI
-
Signal
Uncompressed true 10-bit or 8-bit 422
(playback le dependent)
Supported Loop Out Formats
HDMI to HDMI
720p 50/60, 1080i 50/60,
1080p 24/25/30/50/60/100/120,
4kUHD/4kDCI 24/25/30/50/60
SDI to SDI
-
Gamma/Gamut conversion
Convert loop out to PQ/HLG and BT.2020/DCI-P3/Rec709
Video Signal Conversion
HDMI (4K > HD)
Record/Loop out
Codec
Video to
ProRes / DNxHR
(DNx utilizes a
.MOV wrapper)
Brand / Model /
Codec
Resolution / Frame rate
Apple ProRes HQ,
422, LT
AVID DNxHR
HQX. HQ, SQ, LB
4K DCI; 24/25/30/50/60p
4K UHD; 24/25/30/50/60p
2K
1080p; 24/25/30/50/60/100^/120^
1080i; 50/60i, 720p; 50/60p
Onboard Processing
Pulldown removal
24/25/30pSF > 24/25/30p (2:2 pulldown)
60i > 24p (3:2 pulldown)
4K UHD downscaling
Yes - Loop-out and playback
Audio In/Out (48kHz PCM Audio)
HDMI
2 or 8ch 24-bit, input device dependent
SDI
-
Audio
Line in / Mic in
Headphone out
3.5mm Headphone out 2ch 48kHz 24-bit
Built-in speakers
No
Remote Start/Stop
HDMI
Auto HDMI Trigger
Supported Protocols - Canon, Sony
Atomos Open Standard - Panasonic, Nikon, Olympus, Fuji, Leica
SDI
-
Other
LANC control - Slave
Playback / Slow motion
Playlist
Yes
Genlock / LTC
Yes - with optional AtomX Sync
CDNG (recorded content)
N/A
ProRes (recorded content)
Yes
DNxHR / DNxHD (recorded content)
Yes
Recording
Pre-roll record
Yes (HD 8s, 4K 2s)
Custom timelapse
-
Meta data tagging
Yes (10 tags available)
Supported media
Support for AtomX SSDmini and MasterCaddy II with 2.5”
SSD/HDD (Note: drive will extend beyond drive slot).
Please visit atomos.com/drives for list of approved drives.
Master caddy case
Master Caddy II (included) 75mm x 105mm x 12mm
Master caddy dock
2.5” SATA to USB 2.0/3.0/USB-C 3.1 (not included)
Supported applications
Supported Applications FCPX/FCP7+ / Media Composer 5.0+
Davinci Resolve 8+ / Premiere 5.5 / EDIUS 6.0+
Vegas Pro 10+ / Lightworks / Autodesk Smoke 2015
XML support
FCPX XML native, FCPX/Adobe limited supported with
3rd party conversion tools
What’s in the Box
Included
Ninja V unit, Master Caddy II x 1, 12V-3A AC power supply,
1x Battery Eliminator
Optional extras
Power Kit: 2 x batteries, 1 x charger, 1 x power supply
AtomX Sunhood for Ninja V
AtomX Screen Protector for Ninja V
AtomX SSDmini Handle
Other:
Atomos HDMI cables
USB-C 3.1 Docking Station / USB 2.0 Docking Station
Xrite i1 Display Pro Calibrator and USB to Serial cable
Warranty
1 year. Extended to 3 years on product registration
Construction note: Your Ninja V is designed to operate in ambient temperatures
up to 40°C/104°F. If you wish to extend the temperature of operation in high
temperature conditions, you can choose an SSD drive, and set the TFT brightness to
a minimum.
Please note: Specications are subject to change without notice.
All information assumed correct at time of publishing.
NOV2018-B
13. Technical Specifications
