Atomos Shogun 7 – User Manual Edition 1: November 2019 45
Importing
Final Cut Pro (version 7), Final Cut Pro X, Adobe CS5 (with 5.51 update),
EDIUS 6, Sony Vegas 10, Davinci Resolve 8.0 +, Lightworks and
AvidMediaComposer6supportimportedlesfromyourShogun7disk.
Importing Shogun 7 footage into Final Cut Pro X
You can import Shogun 7 footage into Final Cut Pro X (FCP X) in just a
few simple steps.
First, connect the Shogun 7 Docking Station to your Apple Mac using the
USB 2.0 or USB 3.0 port. Insert the Shogun 7 Master Caddy II containing
the disk with your footage into the Docking Station and you will see the
drive appear in your Finder window.
Start FCPX and open your project (or start a new one).
The screen will look like this:
Go to the File menu and select Import > Media
FCPXwillshowyoua“browse”window.LookfortheShogun7drive,and
click on it.
You’ll see the folders in the Shogun 7 drive. Select the folder containing
the footage you want to import:
Click on Import All or Import Selected, individual clips can be selected.
Choose the Event you wish to import the footage into, or create a new
event.
Select Import:
YourScene,ShotandTakelesnowappearintheprojectwindow,ready
for use in your FCP X project.
12. Connecting & Editing12. Connecting & Editing

Atomos SHOGUN 7 Specifications

General

Internal	No
Product color	Black
Video capturing speed	60 fps
Maximum video resolution	3840 x 2160 pixels
Operating temperature (T-T)	0 - 40 °C
Power consumption (max)	33 W
Built-in display	Yes
Display diagonal	7.2 \

Weight and Dimensions

Depth	45 mm
Width	214 mm
Height	127 mm
Weight	709 g
