Atomos SHOGUN 7 User Manual

OCT2019-A
13. Technical Specifications
Weight and Dimensions
Without batteries
738g / 26oz.
Dimensions (W x H x D mm)
214 x 127 x 45mm
Construction
Glass ber reinforced polycarbonate
Mounting points
1/4”-20 screw mount. 1x top and 1x bottom
Power
Operating power
10 - 33W
Compatible batteries
Atomos NP-F series and supporting accessories
Input voltage (battery)
6.2V to 16.8V
Battery time* (based on 7.4V)
AtomOS 10.2
5200mAh – up to 1hr 10min (monitor & record 4K 60p)
7800mAh – up to 1hr 50min (monitor & record 4K 60p)
DC In
1 x DC in (6.2 - 16.8V)
Continuous power 
Primary-secondary battery system. Change batteries without
losing power. Loop batteries continuously.
Touchscreen
Screen
Capacitive touch
Size
7.2”
Resolution / PPI
1920 x 1080 / 325ppi
Aspect ratio
16:10 native resolution 1920 x 1200
Contrast ratio
1,000,000:1 (Zone backlight turned on)
Color Gamut
Up to Wide color gamut (105% DCI-P3)
Look up table (LUT) support
3D LUT (.cube format)
Anamorphic de-squeeze
2x, 1.5x, 1.33x
Technology
Dynamic AtomHDR zoned backlight IPS LCD
Dynamic AtomHDR Technology
Backlight
Direct LED
Zones
360 direct backlight individual LEDs
LEDs
Wide Color Calibrated D65 or D9
Bit depth
10-bit (8+2 FRC)
Color
DCI-P3 105%
Peak Brightness
3000nit (+/- 10%)
Control
On the y real-time brightness analysis for LED control
HDR Conversion
Log/RAW to HLG or PQ
HDR Monitoring Technology
Technology
IPS panel (capacitive touch),
calibration to Rec.709 with optional calibration unit
AtomHDR
Yes
HDR Monitoring (Gamma)
Sony SLog / SLog2 / SLog3
Canon CLog / CLog2 / Clog3
ARRI Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320 /
LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 /
LogCEI1000 / LogCEI1280 / LogCEI1600
Panasonic Vlog
JVC JLog1
RED Log3G10 / RED LogFilm
FujiFilm F-log
Nikon N-Log
PQ10k
HLG
HDR Monitoring (Gamut)
Sony SGamut / SGamut3 / SGamut3.cine
Canon Cinema / DCI P3 / DCI P3+
Panasonic V Gamut
Arri Alexa Wide Gamut
Rec709 / BT.2020
JVC
RED WideGamut / RED DragonColor / DragonColor2 /
RED Color2 / RED Color3 / RED Color4
Video Input / Loop out
HDMI
HDMI 1 x HDMI (2.0)
SDI
Quad Link 4 x 3G/6G SDI*, 4 x 3G-SDI, 2 x 12G Single Link SDI
Signal
Uncompressed true 10-bit or 8-bit 422 (camera dependent)
Genlock
Genlock input signal and output signal
Video Output (Playout)
HDMI
1 x HDMI (2.0)
SDI
2x 4K-SDI 12G or HD-SDI 3G/6G
HDMI
Uncompressed true 10-bit or 8-bit 4:2:2 (camera dependent)
Onboard Processing
Pulldown removal
24/25/30pSF > 24/25/30p (2:2 pulldown) 60i > 24p (3:2 pulldown)
4K UHD downscale for HD monitoring
Yes - Loop-out and playback (Not available in RAW)
Construction note: Shogun 7 is designed to operate in ambient temperatures up to 40°C/104°F. If you wish
to extend the temperature of operation in high temperature conditions, set the TFT brightness to a minimum.
All specications correct when published, subject to E&OE.
24/30/60 frame rates also means 23.98/29.97/59.94 frame rates for all resolution
*Availableinfuturermwareupdates
^^ Optional unit (XDCA-FS7) needed for Raw output.
 Patent pending.
Supported Codecs & Frame Rates (Record & Playback)
RAW to:
ProRes RAW
ProRes
CinemaDNG (CDNG up to 30p only)
Avid DNxHD, Avid DNxHR
Sony^^
FS700, FS-5, FS-7, FS-7MkII
4K DCI; 24/25/30/50/60p
4K UHD; not supported in camera
2K; 24/25/30/50/60/100/120/200/240p
1080; not supported in camera
Canon
C300MKII/C500 CDNG
4K DCI; 24/25/30p
4K UHD; 24/25/30p
2K; not supported in camera
1080; not supported in camera
Panasonic
VaricamLT, EVA1
5.7K DCI; 24/25/30p (EVA1 ProRes RAW only)
4K DCI; 24/25/30/50/60p
4K UHD; 24/25/30/50/60p
2K; 24/25/30/50/60/100/120/200/240p 1080; not supported in
camera
Supported base resolution & FPS
from cameras
4K DCI: 23.98/29.9/59.94p
4K UHD: 23.98/29.9/59.94p
2K DCI: 23.98/29.9/59.94p
1080p: 23.98/29.9/59.94p
Supported FPS & resolution from
gaming consoles and graphic cards
1080p; 24/25/30/50/60/100/120
Audio Out
HDMI
2 or 8ch 24-bit, camera dependent
SDI
12ch 48kHz 24-bit
Audio
2ch balanced XLR analogue in/out
Dynamic range >90dB
Max signal level +24dBu
Max analogue gain +52dB
48V Phantom Power for Mic
Headphone out
3.5mm 2ch.
Remote Start/Stop
HDMI
Auto HDMI Trigger
Supported Protocols – Dolby Vision, Canon, Sony, Atomos Open
Standard
SDI
SDI trigger camera selectable
Other
LANC control - Slave
Playback
Playlist / Genlock / LTC
Yes / Yes / Yes
CDNG (Recorded content)
No support
ProRes (Recorded content)
All recorded les can playback.
Playback in slow motion >= 100fps
ProRes RAW (recorded content)
All recorded les can playback.
Playback in slow motion >= 100fps
DNxHR / DNxHD (recorded content)
All recorded les can playback.
Playback in slow motion >= 100fps
Recording
Pre-roll record
Yes (HD 8s, 4K 2s)
Custom time lapse
Yes*
Metadata tagging
Yes (10 tags available)
Supported media
2.5” SSD/HDD compatibility depends on recording format,
resolution and frame rate. Visit atomos.com/drives for list of
tested and approved drives
Master caddy case
Master Caddy II (included) 75mm x 105mm x 12mm
Master caddy dock
2.5” SATA to USB 2.0/3.0
Supported applications
Final Cut Pro / Media Composer / Premiere Pro / After Effects /
EDIUS / Vegas Pro / Lightworks / Autodesk Smoke
What’s in the box
Included
Shogun 7 unit, Master Caddy II x 1,
12V-3A AC power supply, Carry Case, Quick Start Guide
Optional extras
Accessories
Power Kit: 2 x battery, 1 x charger, 1 x power supply
Other: Atomos HDMI cables, Breakout XLR cable,
X-Rite i1DisplayPro calibration.
Compatible AtomX accessories: Shogun 7 Sunhood, AtomX
USB-C 3.1 Docking Station II, AtomX SSDmini Handle, AtomX
SSDmini by Angelbird, AtomX SSDmini by Sony ,
Warranty
1 Year
Extended to 3 years on product registration

Atomos SHOGUN 7 Specifications

General

Internal	No
Product color	Black
Video capturing speed	60 fps
Maximum video resolution	3840 x 2160 pixels
Operating temperature (T-T)	0 - 40 °C
Power consumption (max)	33 W
Built-in display	Yes
Display diagonal	7.2 \

Weight and Dimensions

Depth	45 mm
Width	214 mm
Height	127 mm
Weight	709 g
