AudioCodes C455HD - Device Description; Front View

CHAPTER2 Setting up the Phone
C455HD | Users & Administrator's Manual
Device Description
Use  the  following  graphics  to identify  and familiarize  yourself with  the device's  hardware 
functions.
Front View
Thefrontviewofthephoneisshowninthefigureanddescribedinthetable.
Figure 2-1: Front View
Table 2-1: Font View Description
Item # Label/Name Description
1 RingLED Indicatesphonestatus:
■ Green:Idlestate
■ Flashingred:Incomingcall(ringing)
- 13 -
