Page #15 background imageLoading...
Page #15 background image
MSBR Series 15 Mediant 800 MSBR
Hardware Installation Manual 3. Physical Description
3 Physical Description
This section provides a physical description of the device.
Note: The Mediant 800 chassis platform has been upgraded. This revised chassis is
referred to as Mediant 800B; the previous version is referred to as Mediant 800A. The
shipped chassis version depends on your ordered hardware configuration. For more
information, contact your AudioCodes sales representative. In addition, throughout this
manual, the Mediant 800B is used in illustrations, unless specific instructions are
necessary for the Mediant 800A chassis. In such a case, both chassis versions are
shown.
3.1 Physical Dimensions
The device's physical dimensions and weight are listed in the table below:
Table 3-1: Physical Dimensions
Physical Specification Value
Dimensions (W x D x H)
32 x 34.5 cm (12.6 x 13.6 inches) x 1U
Weight
2.5 kg (5.5 lb)
Environmental
Operational: 5 to 40°C (41 to 104°F)
Storage: -25 to 85°C (-13 to 185°F)
Humidity: 10 to 90% non-condensing
