AudioCodes Mediant 800 Hardware Installation Manual

Hardware Installation Manual 22 Document #: LTRT-10229
Mediant 800 MSBR
3.2.2.5 FXS LED
Each FXS port provides a LED for indicating operating status, as described in the table
below.
Table 3-11: FXS LED Description
LED
Color
LED
State
Description
Green
On Phone is off-hooked.
Flashing Rings the extension line.
Red
On
 Error - malfunction in line or out of service due to Serial
Peripheral Interface (SPI) failure
 Disabled port initiated by user (using the CLI command,
analog-port-enable
)
-
Off Phone is on hook.
- Off No power received by the device.
3.2.2.6 FXO LED
Each FXO port provides a LED for indicating operating status, as described in the table
below.
Table 3-12: FXO LED Description
LED
Color
LED
State
Description
Green
On FXO line is off-hooked toward the PBX.
Flashing Ring signal detected from the PBX.
Red
On
 Error - malfunction in line or out of service due to Serial
Peripheral Interface (SPI) failure
 Disabled port initiated by user (using the CLI command,
analog-port-enable
)
-
Off Line is on hook.
- Off No power received by the device.
3.2.2.7 BRI LED
Each BRI port provides a LED for indicating operating status, as described in the table
below:
Table 3-13: BRI LED Description
Color State Description
Green
On Physical layer (Layer 1) is synchronized (normal operation).
Red
On Physical layer (Layer 1) is not synchronized.
- Off
Trunk is not active.

AudioCodes Mediant 800 Specifications

General

Protocols	SIP, H.323
Digital Interfaces	1/2 E1/T1 PRI
Management	Web, CLI, SNMP
Mounting	19-inch rack
Codecs	G.711, G.729, G.722, G.723.1
Power Supply	100-240V AC
Operating Temperature	0 to 40°C
Storage Temperature	-25 to 70°C
Humidity	10% to 90% non-condensing
