PAETEC and Microsoft Lync Integration 60 Document #: LTRT-33420
Mediant 800/1000/3000 E-SBC
5.9.2 Configure Source Phone Number Manipulation
¾ To configure Source Phone Number Manipulation Table for IP -> Tel Calls
Table:
1. Open the ‘Source Phone Number Manipulation Table for IP -> Tel calls’ page
(Configuration tab > VoIP menu > GW and IP to IP > Manipulations submenu
> Source Number IP >Tel).
Figure
5-25: Source Phone Number Manipulation Table for IP -> Tel Calls Page
• Index #1 defines Source number manipulation of IP calls from Lync
Mediation Server. All calls received from IP address 10.15.9.11 (i.e., from
Lync Mediation Server) and the source number prefix begins with '+1',
remove the ‘+1’ from the number.
• Index #2 defines Source number manipulation of IP calls from Lync
Mediation Server. All calls received from IP address 10.15.9.11 (i.e., from
Lync Mediation Server) and the source number prefix begins with '+', remove
the ‘+’ from the number.
• Index #3 defines Source number manipulation of IP calls from Lync
Mediation Server. All calls received from IP address 10.15.9.11 (i.e., from
Lync Mediation Server) and the source number prefix begins with '1', remove
the ‘1’ from the number.
• Index #4 defines Source number manipulation of anonymous calls from
Lync Mediation Server. Anonymous calls received from IP address
10.15.9.11 (i.e., from Lync Mediation Server) replace the ‘anonymous’ caller
ID with a modified well-known number, i.e., a7192083390. This manipulation
is performed to create a well-known number in the P-Asserted-Identity
header. Without this number, the PAETEC SIP Trunk could potentially reject
the call. See below (in the
Source Phone Number Manipulation Table for Tel
-> IP index #4) for the Source Number manipulation Tel->IP manipulation
rule that restricts the caller ID for an anonymous call.
