ADVANCED MANUAL / Bit One /
25
Ex.: the 1 and 2 outputs could be assigned to the rear
channels just because with this setting the cables
going to the relative amplifier would not need to be
lengthened.
6. Processor outputs (Ch1÷Ch8) allocation
While performing the set-up, the software will
automatically notify the return within the 8 output channel
limit, the warning message will then disappear and the
NEXT button will appear.
Press BACK to go back to the previous step.
Press NEXT to go ahead with the set-up procedure.
Press CANCEL to exit the program.
5.
How to select passive crossovers for speaker groups
While carrying out the configuration of your system, you
can also set the presence of passive crossovers managing
speaker functional groups in complex systems.
Ex.: The 3-way Front can be managed as:
- multi-amplified (6 output channels would be required);
- passive mid-high speakers + separately amplified
woofer (4 output channels would be required);
- 3-way passive (2 output channels would be required).
The Bit One features 8 output channels. On this
specific step of the procedure, any signal can be
assigned to each output channel.
Due to a matter of convenience, if the output 1
is assigned to the left woofers, the software will
automatically assign the output 2 to the right woofers.
If during the procedure the output 1 is assigned also
to the left mid-high speakers, the software will show
a warning message. Change the allocation of one of
the two numbers marked in red and the software will
automatically select the first available channel.
Press BACK to go back to the previous step.
Press NEXT to go ahead with the set-up procedure.
Press CANCEL to exit the program.
Screen
sequence
5
6
8
