AUTOFLAME MK8 User Manual

11
Errors & Lockouts
Flame Safeguard (MM80001/FSG) Manual
Page | 151
Setting Conflict Message
(30) (31) Invalid remote setpoint configuration
• The Minimum Remote Setpoint (DTI/Modbus/External) cannot be set higher than the Maximum
Remote Setpoint (DTI/Modbus/External) and vice versa.
• Check options 30 and 31.
(43) (44) (E1) Water level control only be on the multi-burner master
• Water level control should only be enabled on the master (multi-burner ID 1 set in option 44), when
using the multi-burner function.
• Check options 43, 44 and expansion option 1.
(43) (44) (16) Sequencing only be only the multi-burner master
• Only the master (multi-burner ID 1 set in option 44) can be set for sequencing.
• Check options 16, 43 and 44.
(43) (44) (12) EGA and trim can only be on the multi-burner master
• Only the master (multi-burner ID 1 set in option 44) can be optioned with an EGA.
• Check options 12, 43 and 44.
(43) (44) (E110) First Outs can only be on the multi-burner master
• Only the master (multi-burner ID 1 set in option 44) can have first outs enabled.
• Check options 43, 44 and expansion option 110.
(43) (44) (E120) Heat-flow can only be on the multi-burner master
• Only the master (multi-burner ID 1 set in option 44) can have heat flow function enabled.
• Check options 43, 44 and expansion option 120.
(43) (44) (45) External modulation can only be on the multi-burner master
• Only the master (multi-burner ID 1 set in option 4) can be set for external modulation.
• Check options 43 – 45.
(43) (44) (E82) Draught control can only be on the multi-burner master.
• Only the master (multi-burner ID 1 set in option 44) can be set for draught control.
• Check options 43, 44 and expansion option 82.
(43) (44) (47) Cold Start should only be optioned on the Multi-Burner Master
• Only the master (multi-burner ID 1 set in option 44) can be se for cold start.
• Check options 43, 44 and 47
(43) (52) Differential Firing Rate Limit requires Fully-Linked Multi-Burner
• Differential Firing Rate Limit requires Fully- Linked Multi-Burner operation
• Check options 43 and 52
(43) (57) Fuel flow metering must be enabled for multi-burner
• The multi-burner function requires fuel flow metering.
• Check options 43 and 57.
(43) (111) Continuous Pilot is not supported for Fully-Linked Multi-Burner
• Continuous pilot cannot be used in Fully-Linked Multi-Burner operation
• Check options 43 and 111
(43) (135) NFPA Post Purge cannot be optioned with multi-burner
• The multi-burner function can only use standard, not NFA post-purge.
• Check option 43 and option/parameter 135.
(43) (P100) Assured Low-Fire Shut Off not supported for Fully-Linked Multi-Burner
• Assure Low-Fire Shut Off cannot be used with Fully-Linked Multi-Burner operation
• Check option 43 and parameter 100
(44) (52) Differential Firing Rate Limit should only be set on the Multi-Burner master
• Only the Multi-Burner master (multi-burner ID 1 set on option 44) can have Differential Firing Rate
Limit enabled
• Check options 44 and 52
(45) (55) External modulation option conflict
• Switched T88 external modulation is not set with permanent external modulation.
• Check options 45 and 55.
