Autoflame Flame Safeguard Overview, Specifications and Wiring

Flame Safeguard (MM80001/FSG) Manual

Page | 28

1.4.8

Expansion Board Terminals Description

All terminals marked S are internally connected. They are provided for connections to the

various screened cables.

FO1

First Out annunciation line voltage input 1

FO2

First Out annunciation line voltage input 2

FO3

First Out annunciation line voltage input 3

FO4

First Out annunciation line voltage input 4

FO5

First Out annunciation line voltage input 5

FO6

First Out annunciation line voltage input 6

FO7

First Out annunciation line voltage input 7

FO8

First Out annunciation line voltage input 8

FO9

First Out annunciation line voltage input 9

FO10

First Out annunciation line voltage input 10

FO11

First Out annunciation line voltage input 11

FO12

First Out annunciation line voltage input 12

Power feed 2A output (230V/110V)

FO13

First Out annunciation line voltage input 13

FO14

First Out annunciation line voltage input 14

FO15

First Out annunciation line voltage input 15
