Autoflame Flame Safeguard Overview, Specifications and Wiring
Flame Safeguard (MM80001/FSG) Manual
Page | 22
1.3.4 Fuse Ratings
Fu se
Rating
Spare P art Num ber
1
6.3A (T)
FU10026
Fuse 1 protects the mains input to the MM, including the mains output terminals 50 – 64.
2
2A (T)
FU10034
Fuse 2 protects the power supply (terminal 69) for the servomotors, alarm and 2 port valve. If this fuse blows,
error ‘Triac Power Supply Error (Check F2)’ will occur.
3
500mA
FU10040
Fuse 3 protects the 13.5V power supply to the oil pressure sensor and IR scanner on terminal 49. If this fuse
blows, error ‘Fused 13.5V Supply Error (Check F3)’ will occur.
4
500mA
FU10040
Fuse 4 protects the 12V power supply to the gas/air pressure sensor and steam pressure detector on
terminals 34 and 39. If this fuse blows, error ‘Fused 12V Supply Error (Check F4)’ will occur.
5
2A (T)
FU10034
Fuse 5 protects the power supply (terminal PF) for the expansion servos and alarm outputs. If fuse 5 blows,
error ‘Expansion PF Output (Check F5)’ will occur.
6
2A
FU10027
Fuse 6 protects the DC circuits. If this fuse blows, the display will be off and both LEDs adjacent to fuse 7
and 8 will be off.
7
4A
FU10050
Fuse 7 protects the internal 5V supply. If this fuse blows the display will be off and the LED adjacent to the
fuse will be off.
8
2.5A
FU10042
Fuse 8 protects the internal 12V supply. If this fuse blows the display will be off and the LED adjacent to the
fuse will be off.
