AUTOFLAME MK8 User Manual

1
Autoflame Flame Safeguard Overview, Specifications and Wiring
Flame Safeguard (MM80001/FSG) Manual
Page | 27
85
Mains voltage input. For use when using an external flame switch- 0V when at no flame state
86
Mains voltage input. For use when using an external flame switch- line voltage when at no
flame state
89
Mains voltage input – selects fuel 1 curve
90
Mains voltage input – selects fuel 2 curve
91
Mains voltage input – selects fuel 3 curve
92
Mains voltage input – selects fuel 4 curve
Note that outputs T70 and T71 are switched neutrals and must be connected to the motor through relays.
Autoflame provide the relay box (SP80070, SP80070/110) to facilitate this. Alternatively, relays may be wired
in as per the wiring schematic in section 1.3.1.

AUTOFLAME MK8 Specifications

General

Brand	AUTOFLAME
Model	MK8
Category	Controller
Language	English
