AUTOFLAME MK8 User Manual

11
Errors & Lockouts
Flame Safeguard (MM80001/FSG) Manual
Page | 153
Setting Conflict Message
(E1) (1) Water level control requires a boiler pressure sensor.
• Water level control cannot be used with a hot water boiler (load/external temperature detector).
• Check expansion option 1 and option 1.
(E1) (E3, E4) At least one analogue level sensor required.
• If water level is enabled with one capacitance probe, then an external level sensor is required.
• Check expansion options 1, 3 and 4.
(E1) (E3, E4, E5, E6) Sensor enabled but water level control disabled.
• Water level control enabled must be enabled if capacitance probes, external level sensor, 2
nd
low
probe or auxiliary water level alarm inputs are set.
• Check expansion options 1, 3, 4, 5 and 6.
(E3, E4, E5, E6) At least two level sensing elements are required.
• A minimum of two of the following level sensing elements is required: capacitance probe, external
level sensor, auxiliary water level alarm input or second low probe.
• Check expansion options 3, 4, 5 and 6.
(E4) (E30) External level sensor without scaling requires a capacitance probe.
• Check expansion options 4 & 30
(E4) (57) External level sensor cannot be optioned with fuel flow feedback
• External level sensor cannot be used with fuel flow feedback, as they use same terminals.
• Check expansion option 4 and option 57.
(E11) (E12) Pump turn off point must be above pump turn on point.
• Pump turn off point cannot be set lower than pump turn on point.
• Check expansion options 11 and 12.
(E17) (E40) Bypass valve cannot be optioned with solenoid top blowdown.
• Bypass and solenoid top blowdown cannot be used together, as they use same terminals.
• Check expansion options 17 and 40.
(E28) (E3) External level sensor without scaling requires a capacitance probe.
• If external level sensor does not have a scale to indicate what level the 4-20mA signal
represents, a capacitance probe is required.
• Check expansion options 3 and 38.
(E30) External probe scaling must be less than 8 inches/mA.
• Check expansion option 30
(E40) (1) Top blowdown requires a boiler pressure sensor.
• Top blowdown cannot be used with a hot water boiler (load/external temperature detector).
• Check expansion option 40 and option 1.
(E42) (E46) TDS warning level less than TDS target.
• TDS warning level cannot be set lower than the TDS target value.
• Check expansion options 42 and 46.
(E60) (1) Bottom blowdown requires a boiler pressure sensor.
• Bottom blowdown cannot be used with a hot water boiler (load/external temperature detector).
(E62) (E64) Bottom blowdown reduction boiler steam production rating not set.
• If bottom blowdown reduction is enabled, then steam production rating must be set.
• Check expansion options 62 and 64.
(E62) (E120) Bottom blowdown reduction requires steam flow to be enabled.
• If bottom blowdown reduction is enabled, then steam flow metering must be enabled.
• Check expansion options 62 and 120.
(E80) (E82) Draught control enabled but draught servo disabled.
• Draught servomotor must be enabled for draught control.
• Check expansion options 80 and 82.
(E80) (E115) Draught Servo configured as commissioned servo and for temperature PID
• Check expansion options 80 and 115
