AUTOFLAME MK8 User Manual

2
Options & Parameters
Flame Safeguard (MM80001/FSG) Manual
Page | 49
Opt. #
Default
Range
Description
85
0
MM: Night Setback Offset
This offset value is subtracted from the required setpoint. An input is
required on terminal 93, see option 79.
0
Disabled
1 – 100
O
C,
O
F, PSI or 0.1 bar or 0.01 bar for low pressure sensor (depends on
load detector set in option 1 and metric/imperial units set in parameter 40)
86
0
MM: Channel 1 Servo Control Method
0
Autoflame Servo Motor, 0.1 degree control
1
Autoflame Servo Motor, 0.5 degree control
2
Industrial Servo Motor, 0.1 degree control
3
Industrial Servo Motor, 0.5 degree control
4
IO Unit 4-20mA Servo Motor, 0.5 degree control
5
IO Unit 4-20mA Servo Motor, 1.0 degree control
87
0
MM: Channel 2 Servo Control Method
0
Autoflame Servo Motor, 0.1 degree control
1
Autoflame Servo Motor, 0.5 degree control
2
Industrial Servo Motor, 0.1 degree control
3
Industrial Servo Motor, 0.5 degree control
4
IO Unit 4-20mA Servo Motor, 0.5 degree control
5
IO Unit 4-20mA Servo Motor, 1.0 degree control
88
0
MM: Channel 3 Servo Control Method
0
Autoflame Servo Motor, 0.1 degree control
1
Autoflame Servo Motor, 0.5 degree control
2
Industrial Servo Motor, 0.1 degree control
3
Industrial Servo Motor, 0.5 degree control
4
IO Unit 4-20mA Servo Motor, 0.5 degree control
5
IO Unit 4-20mA Servo Motor, 1.0 degree control
89
0
MM: Channel 4 Servo Control Method
0
Autoflame Servo Motor, 0.1 degree control
1
Autoflame Servo Motor, 0.5 degree control
2
Industrial Servo Motor, 0.1 degree control
3
Industrial Servo Motor, 0.5 degree control
4
IO Unit 4-20mA Servo Motor, 0.5 degree control
5
IO Unit 4-20mA Servo Motor, 1.0 degree control
90
0
MM: VSD Operation Channel 5
0
Disabled
1
Enabled
91
0
MM: Output from MM to VSD Channel 5
0
Output range 4 to 20mA
1
Output range 0 to 20mA
2
Output range 0 to 10V
92
0
MM: Output Units Displayed, VSD Channel 5
0
Selected output signal
1
Hertz
93
25
MM: Output Low Speed from MM to VSD Channel 5
1 – 200
Hertz
94
50
MM: Output High Speed from MM to VSD Channel 5
1 – 200
Hertz
