Options & Parameters
Flame Safeguard (MM80001/FSG) Manual
Page | 63
Par.#
Default
Range
Description
47
0
DTI: Standby or Phantom Setpoint Type
0
1
Instead of a fixed setpoint when the MM is in standby mode, it would have
It’s current setpoint offset down by a value instead. When configured for
Phantom Setpoint, the Standby Setpoint Option 42 becomes a Phantom
Setpoint Offset.
Use Fixed Standby Setpoint
Use Phantom Setpoint Offset
48
80
PID: Integral Band
0 – 100
This is the percentage of the proportional band over which the integral
control is active.
0% - 100%
52
0
MM: External Load Detector – Number of Decimal Places
This affects parameter the external load detector maximum and minimum
values set in parameters 53 and 55. See option 1 and parameter 40.
0
0 decimal place
1
1 decimal place
2
2 decimal places
53
20
MM: External Load Detector – Maximum Value
0 – 9990
The scale will depend on how parameter 52 is set. See option 1 and
parameter 40.
Bar (PSI) or
O
C (
O
F)
20 = 20 Bar (PSI) or
O
C (
O
F) if parameter 52 is set to 0
20 = 2.0 Bar (PSI) or
O
C (
O
F) if parameter 52 is set to 1
20 = 0.2 Bar (PSI) or
O
C (
O
F) if parameter 52 is set to 2
54
0
MM: External Load Detector – Maximum Voltage
0 – 100
0.0V – 10.0V
55
20
MM: External Load Detector – Minimum Value
0 – 9990
The scale will depend on how parameter 52 is set. See option 1 and
parameter 40.
Bar (PSI) or
O
C (
O
F)
20 = 20 Bar (PSI) or
O
C (
O
F) if parameter 52 is set to 0
20 = 2.0 Bar (PSI) or
O
C (
O
F) if parameter 52 is set to 1
20 = 0.2 Bar (PSI) or
O
C (
O
F) if parameter 52 is set to 2
56
0
MM: External Load Detector – Minimum Voltage
0 – 100
0.0V – 10.0V
57
10
DTI: Highest MM ID
1 –10
This sets the highest MM ID number for that sequence or DTI loop.
Sequence ID
58
1
EGA: Air Calibration on Startup
For the Mk8 EGA, the air calibration schedule is set on the EGA itself.
0
Disabled
1
Enabled
59
-
Unused
60
60
MM: Logo Display Timer (Standby)
If a custom logo is stored on the data SD card in the MM, then after this
timer in standby mode, the custom logo will appear on the screen.
0
Disabled
1 – 3600
Seconds
