AUTOFLAME MK8 User Manual

5
Expansion Features
Flame Safeguard (MM80001/FSG) Manual
Page | 85
#
Type
Description
Details
30101
RA
Load Index
Firing rate %
30102
RA
Firing Status
0 = Non-modulating
1 = Modulating
Returns value 0 single point change, fuel flow metering
and commissioning
*For Setting 1 see section 6.4.1
30104
RA
Burner Rating
MW x 10
Metric units determined from fuel flow metering
30105
RA
Actual Value
Imperial: temperature °F, pressure PSI, low pressure PSI
x 10
30106
RA
Required Value
Metric: temperature °C, pressure Bar x 10, low pressure
Bar x 100
Imperial: temperature °F, pressure PSI, low pressure PSI
x 10
30107
RA
Selected Fuel
0 = Fuel 1
1 = Fuel 2
2 = Fuel 3
3 = Fuel 4
30109
RA
Channel 1 Position
Degrees x 10
Range is -6.0° to 96.0°
30110
RA
Channel 2 Position
Degrees x 10
Range is -6.0° to 96.0°
30111
RA
Channel 3 Position
Degrees x 10
Range is -6.0° to 96.0°
30112
RA
Channel 4 Position
Degrees x 10
Range is -6.0° to 96.0°
30113
RA
MM Error Number
0 = System is does not have an error
N = error number, check error codes
30114
RA
Multi-Burner ID
MM ID number set in option 44
30115
RA
EGA Current O
2
Value
% x 10
30116
RA
EGA Current CO
2
Value
% x 10
30117
RA
EGA Current CO Value
ppm x 10
30118
RA
EGA Current Exhaust Gas
Temperature
Metric: temperature x 10 °C
Imperial: temperature x 10 °F
30119
RA
EGA Current Efficiency Value
% x 10
30120
RA
EGA Current NO Value
ppm x 10
30121
RA
EGA Current SO
2
Value
ppm x 10
30122
RA
EGA Commissioned O
2
Value
% x 10
30123
RA
EGA Commissioned CO
2
Value
% x 10
30124
RA
EGA Commissioned CO Value
ppm x 10
30125
RA
EGA Commissioned Exhaust
Gas Temperature
Metric: temperature x 10 °C
Imperial: temperature x 10 °F
30126
RA
EGA Commissioned Efficiency
Value
% x 10
30127
RA
EGA Commissioned NO Value
ppm x 10
30128
RA
EGA Commissioned SO
2
Value
ppm x 10
30129
RA
EGA Error Code
0 = EGA does not have a fault,
N = EGA error
30130
RA
Minimum Remote Setpoint
Metric: temperature °C, pressure Bar x 10, low pressure
mbar x 100
Imperial: temperature °F, pressure PSI, low pressure PSI
x 10
30131
RA
Maximum Remote Setpoint
Metric: temperature °C, pressure Bar x 10,
low pressure mbar x 100
Imperial: temperature °F, pressure PSI,
low pressure PSI x 10
