AUTOFLAME MK8 User Manual

5
Expansion Features
Flame Safeguard (MM80001/FSG) Manual
Page | 87
#
Type
Description
Details
30149
RA
Flame Switch Status
0 = Off
1 = On
30150
RA
EGA Current NO
2
Value
ppm x 10
30151
RA
EGA Commissioned NO
2
Value
ppm x 10
30801
RA
Fuel 4 Flow Total Thousands
Metric kW/hr
Imperial MMBTU/hr
Remainder after whole number of MW/hr or MMBTU x
1000 taken away, x 1000. E.g. 1.5MW/hr gives 500 value
and 15.1MMBTU gives 100 value
30802
RA
Fuel 4 Flow Total Millions
Metric MW/h
Imperial MMBTU
Whole number of MW/hr or MMBTU. E.g. 1.5MW/hr gives
1 value and 15.1MMBTU gives 15 value
30803
RA
Fuel 4 Flow Total Billions
Metric GW/hr
Imperial MMBTU / 1000
Whole number of GW/hr or MMMBTU E.g. 1.5MW/hr
gives 0 value and 15.1MMBTU gives 0 value
30804
RA
VSD 1 Output
mA x 10 or V x 10
30805
RA
VSD 1 Input
mA x 10 or V x 10
30806
RA
VSD 2 Output
mA x 10 or V x 10
30807
RA
VSD 2 Input
mA x 10 or V x 10
30808
RA
Channel 7 Position
Degrees x 10
Range is -6.0° to 96.0°
30830
RA
Lockout Number
0 = System is not in lockout
N = lockout number
30831
RA
Fuel 1 Type
0 = Gas
1 = Oil
Option / Parameter 150 value
30832
RA
Fuel 2 Type
0 = Gas
1 = Oil
Option / Parameter 151 value
30833
RA
Fuel 3 Type
0 = Gas
1 = Oil
Option / Parameter 152 value
30834
RA
Fuel 4 Type
0 = Gas
1 = Oil
Option / Parameter 153 value
30839
RA
Fuel 1 Hours Run
Completed hours
30840
RA
Fuel 2 Hours Run
Completed hours
30841
RA
Fuel 3 Hours Run
Completed hours
30842
RA
Fuel 4 Hours Run
Completed hours
30843
RA
Fuel 1 Start-ups
Number of start-ups on Fuel 1
30844
RA
Fuel 2 Start-ups
Number of start-ups on Fuel 2
30845
RA
Fuel 3 Start-ups
Number of start-ups on Fuel 3
30846
RA
Fuel 4 Start-ups
Number of start-ups on Fuel 4
30847
RA
Current Air Pressure
mbar x 10
“wg x 10
Parameter 43 value
30849
RA
Current Gas Pressure
mbar x 10
“wg x 10
PSI x 100
Parameter 41 value
32001
RA
Capacitance Probe 1 Signal
Hz reading
32002
RA
Capacitance Probe 1 Reading
on MM
Metric: mm
Imperial: inches x 10
