AUTOFLAME MK8 User Manual

5
Expansion Features
Flame Safeguard (MM80001/FSG) Manual
Page | 89
#
Type
Description
Details
32053
RA
Auxiliary High Water Input
0 = Input not active
1 = input active
32054
RA
Auxiliary 1
st
Low Input
0 = Input not active
1 = input active
32055
RA
Auxiliary 2
nd
Low Input
0 = Input not active
1 = input active
32056
RA
Combined Water level Reading
Depth
Metric: mm
Imperial: inches x 10
32057
RA
Current steam flow, high word
Lb/hr
Lbs per hour
This is an extension of the existing address 32016. If the
value gets too large to fit in a 16 bit Modbus register this
address holds any value greater than 65535, in the same
way that the existing registers with high word/low word
work.
Value = (65536 * high word) + low word
32058
RA
Current steam flow, high word
Kg/hr
Kgs per hour
This is an extension of the existing address 32027. If the
value gets too large to fit in a 16 bit Modbus register this
address holds any value greater than 65535, in the same
way that the existing registers with high word/low word
work.
Value = (65536 * high word) + low word
32060
RA
Makeup water temperature
°C
32061
RA
Condensate temperature
°C
32062
RA
Water in temperature
°C
32063
RA
Economiser input temperature
°C
32064
RA
Economiser output temperature
°C
32065
RA
Make up temperature
°F
32066
RA
Condensate temperature
°F
32067
RA
Water in temperature
°F
32068
RA
Economiser input temperature
°F
32069
RA
Economiser output temperature
°F
33001
RA
Fully Metered Excess Air
Reading Valid
0 = Invalid reading
1 = Valid reading
33002
RA
Fully Metered Current Excess
Air %
Excess air % x 1000
33003
RA
Fully Metered Commissioned
Excess Air %
Excess air % x 1000
33010
RA
Fully Metered Current Fuel
Mass Flow Thousands
Metric: kgs x 1000
Imperial: lbs x 1000
33011
RA
Fully Metered Current Fuel
Mass Flow Singles
Metric: 0 to 999 kgs
Imperial: 0 to 999 lbs
33012
RA
Fully Metered Commissioned
Fuel Mass Flow Thousands
Metric: kgs x 1000
Imperial: lbs x 1000
33013
RA
Fully Metered Commissioned
Fuel Mass Flow Singles
Metric: 0 to 999 kgs
Imperial: 0 to 999 lbs
33014
RA
Fully Metered Current Fuel
Volume Flow Thousands
m
3
per hour
33015
RA
Fully Metered Current Fuel
Volume Flow Singles
m
3
per hour
33016
RA
Fully Metered Fuel Flow Meter
Current (4-20mA) Signal
mA x 10
33017
RA
Fully Metered Fuel
Temperature
Metric: °C x10
Imperial: °F x 10
