Chapter 3: Configuration and Parameters
parameTer deTails – “log” menu of parameTers (ConTinued)
Each SR55 is tested at the factory, and each unit may have a brief log history from this
testing.
P20.1 – Last Temperature -1 Type:
Description: Read Only
Displays the heatsink temperature at the end of the last successful start -1.
Range: Modbus Decimal Value: Default:
-20°C to 80°C bit12=0 [HighByte*16
+ LowByte/16]bit12=1
256-[HighByte*16 + LowByte/16]
ambient °C
Modbus Address: Modbus Format:
39681 ( 9B01 hex ) 16-bit (Highbyte=b11-b8,
LowByte=b7-b0) Ta >= 0 b12=0 Ta
< 0 b12=1
Touchscreen Menu Path:
Home → Log → Temperature Log → Last Temperature -1
P20.2 – Last Temperature -2 Type:
Description: Read Only
Displays the heatsink temperature at the end of the last successful start -2.
Range: Modbus Decimal Value: Default:
-20°C to 80°C bit12=0 [HighByte*16
+ LowByte/16]bit12=1
256-[HighByte*16 + LowByte/16]
ambient °C
Modbus Address: Modbus Format:
39682 ( 9B02 hex ) 16-bit (Highbyte=b11-b8,
LowByte=b7-b0) Ta >= 0 b12=0 Ta
< 0 b12=1
Touchscreen Menu Path:
Home → Log → Temperature Log → Last Temperature -2
P20.3 – Last Temperature -3 Type:
Description: Read Only
Displays the heatsink temperature at the end of the last successful start -3.
Range: Modbus Decimal Value: Default:
-20°C to 80°C bit12=0 [HighByte*16
+ LowByte/16]bit12=1
256-[HighByte*16 + LowByte/16]
ambient °C
Modbus Address: Modbus Format:
39683 ( 9B03 hex ) 16-bit (Highbyte=b11-b8,
LowByte=b7-b0) Ta >= 0 b12=0 Ta
< 0 b12=1
Touchscreen Menu Path:
Home → Log → Temperature Log → Last Temperature -3
