Chapter 3: Configuration and Parameters
Page 3–71Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
parameTer deTails – “log” menu of parameTers (ConTinued)
Each SR55 is tested at the factory, and each unit may have a brief log history from this
testing.
P19.8 – Last Peak Stop Current -8 Type:
Description:
Read Only
Displays the peak current of the last successful stop -8.
Range: Modbus Decimal Value: Default:
• Peak Current: 0A – 10,000A
• Peak Current Time: hh:mm:ss
• linear scale (1 = 1mA)
Current (A) = (Value / 1000)
• Time (ms) since midnight
(bytes5,4,3,2) and Days since
01/01/1984 (bytes1,0)
• 0A
• GMT
Modbus Address: Modbus Format:
• Peak Current: 39056/39057 ( 9890/9891 hex )
• Peak Current Time: 39128/39129/39130 ( 98D8/98D9/98DA hex )
• 32-bit unsigned
• 6 Bytes
Touchscreen Menu Path:
Home → Log → Stop Current Log → Last Peak Stop Current -8
P19.9 – Last Peak Stop Current -9 Type:
Description:
Read Only
Displays the peak current of the last successful stop -9.
Range: Modbus Decimal Value: Default:
• Peak Current: 0A – 10,000A
• Peak Current Time: hh:mm:ss
• linear scale (1 = 1mA)
Current (A) = (Value / 1000)
• Time (ms) since midnight
(bytes5,4,3,2) and Days since
01/01/1984 (bytes1,0)
• 0A
• GMT
Modbus Address: Modbus Format:
• Peak Current: 39058/39059 ( 9892/9893 hex )
• Peak Current Time: 39131/39132/39133 ( 98DB/98DC/98DD hex )
• 32-bit unsigned
• 6 Bytes
Touchscreen Menu Path:
Home → Log → Stop Current Log → Last Peak Stop Current -9
log “TemperaTure log” parameTers
P20.0 – Last Temperature Type:
Description:
Read Only
Displays the heatsink temperature at the end of the last successful start.
Range: Modbus Decimal Value: Default:
-20°C to 80°C bit12=0 [HighByte*16
+ LowByte/16]bit12=1
256-[HighByte*16 + LowByte/16]
ambient °C
Modbus Address: Modbus Format:
39680 ( 9B00 hex ) 16-bit (Highbyte=b11-b8,
LowByte=b7-b0) Ta >= 0 b12=0 Ta
< 0 b12=1
Touchscreen Menu Path:
Home → Log → Temperature Log → Last Temperature
