Automation Direct Stellar SR55 Series User Manual

Page 3–70 Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
Chapter 3: Configuration and Parameters
parameTer deTails – “log” menu of parameTers (ConTinued)
Each SR55 is tested at the factory, and each unit may have a brief log history from this
testing.
P19.5 – Last Stop Current -5 Type:
Description: Read Only
Displays the peak current of the last successful stop -5.
Range: Modbus Decimal Value: Default:
• Peak Current: 0A – 10,000A
• Peak Current Time: hh:mm:ss
• linear scale (1 = 1mA)
Current (A) = (Value / 1000)
• Time (ms) since midnight
(bytes5,4,3,2) and Days since
01/01/1984 (bytes1,0)
• 0A
• GMT
Modbus Address: Modbus Format:
• Peak Current: 39050/39051 ( 988A/988B hex )
• Peak Current Time: 39119/39120/39121 ( 98CF/98D0/98D1 hex )
• 32-bit unsigned
• 6 Bytes
Touchscreen Menu Path:
Home → Log → Stop Current Log → Last Peak Stop Current -5
P19.6 – Last Peak Stop Current -6 Type:
Description: Read Only
Displays the peak current of the last successful stop -6.
Range: Modbus Decimal Value: Default:
• Peak Current: 0A – 10,000A
• Peak Current Time: hh:mm:ss
• linear scale (1 = 1mA)
Current (A) = (Value / 1000)
• Time (ms) since midnight
(bytes5,4,3,2) and Days since
01/01/1984 (bytes1,0)
• 0A
• GMT
Modbus Address: Modbus Format:
• Peak Current: 39052/39053 ( 988C/988D hex )
• Peak Current Time: 39122/39123/39124 ( 98D2/98D3/98D4 hex )
• 32-bit unsigned
• 6 Bytes
Touchscreen Menu Path:
Home → Log → Stop Current Log → Last Peak Stop Current -6
P19.7 – Last Peak Stop Current -7 Type:
Description: Read Only
Displays the peak current of the last successful stop -7.
Range: Modbus Decimal Value: Default:
• Peak Current: 0A – 10,000A
• Peak Current Time: hh:mm:ss
• linear scale (1 = 1mA)
Current (A) = (Value / 1000)
• Time (ms) since midnight
(bytes5,4,3,2) and Days since
01/01/1984 (bytes1,0)
• 0A
• GMT
Modbus Address: Modbus Format:
• Peak Current: 39054/39055 ( 988E/988F hex )
• Peak Current Time: 39125/39126/39127 ( 98D5/98D6/98D7 hex )
• 32-bit unsigned
• 6 Bytes
Touchscreen Menu Path:
Home → Log → Stop Current Log → Last Peak Stop Current -7
