Page 3–74 Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
Chapter 3: Configuration and Parameters
parameTer deTails – “log” menu of parameTers (ConTinued)
Each SR55 is tested at the factory, and each unit may have a brief log history from this
testing.
P20.7 – Last Temperature -7 Type:
Description: Read Only
Displays the heatsink temperature at the end of the last successful start -7.
Range: Modbus Decimal Value: Default:
-20°C to 80°C bit12=0 [HighByte*16
+ LowByte/16]bit12=1
256-[HighByte*16 + LowByte/16]
ambient °C
Modbus Address: Modbus Format:
39687 ( 9B07 hex ) 16-bit (Highbyte=b11-b8,
LowByte=b7-b0) Ta >= 0 b12=0 Ta
< 0 b12=1
Touchscreen Menu Path:
Home → Log → Temperature Log → Last Temperature -7
P20.8 – Last Temperature -8 Type:
Description: Read Only
Displays the heatsink temperature at the end of the last successful start -8.
Range: Modbus Decimal Value: Default:
-20°C to 80°C bit12=0 [HighByte*16
+ LowByte/16]bit12=1
256-[HighByte*16 + LowByte/16]
ambient °C
Modbus Address: Modbus Format:
39688 ( 9B08 hex ) 16-bit (Highbyte=b11-b8,
LowByte=b7-b0) Ta >= 0 b12=0 Ta
< 0 b12=1
Touchscreen Menu Path:
Home → Log → Temperature Log → Last Temperature -8
P20.9 – Last Temperature -9 Type:
Description: Read Only
Displays the heatsink temperature at the end of the last successful start -9.
Range: Modbus Decimal Value: Default:
-20°C to 80°C bit12=0 [HighByte*16
+ LowByte/16]bit12=1
256-[HighByte*16 + LowByte/16]
ambient °C
Modbus Address: Modbus Format:
39689 ( 9B09 hex ) 16-bit (Highbyte=b11-b8,
LowByte=b7-b0) Ta >= 0 b12=0 Ta
< 0 b12=1
Touchscreen Menu Path:
Home → Log → Temperature Log → Last Temperature -9
