Automation Direct Stellar SR55 Series User Manual

Chapter 3: Configuration and Parameters
Page 3–19Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
parameTers assoCiaTed WiTh bloCk Transfers
P0.20~P0.35 – Block Transfer Address Pointers Hold. Reg. Type:
Description: Read/Write
Address pointers for data block transfer.
• For details, please refer to “Block Transfer Parameters” on page 3–14.
Range: Modbus Decimal Value: Default (decimal):
• 0~65535 • 65535 • Off (0)
Modbus Addresses: Modbus Format:
17600 ( 44C0 hex )
17601 ( 44C1 hex )
17602 ( 44C2 hex )
17603 ( 44C3 hex )
17604 ( 44C4 hex )
17605 ( 44C5 hex )
17606 ( 44C6 hex )
17607 ( 44C7 hex )
17608 ( 44C8 hex )
17609 ( 44C9 hex )
17610 ( 44CA hex )
17611 ( 44CB hex )
17612 ( 44CC hex )
17613 ( 44CD hex )
17614 ( 44CE hex )
17615 ( 44CF hex )
16-bit unsigned
Touchscreen Menu Path:
none
P0.40~P0.55 – Block Transfer Data Locations Hold. Reg. Type:
Description: Read/Write
Data locations for data block transfer.
• For details, please refer to “Block Transfer Parameters” on page 3–14.
Range: Modbus Decimal Value: Default (decimal):
• 0~4,294,967,295 • 4,294,967,295 • Off (0)
Modbus Addresses: Modbus Format:
P0.40
P0.41
P0.42
P0.43
P0.44
P0.45
P0.46
P0.47
P0.48
P0.49
P0.50
P0.51
P0.52
P0.53
P0.54
P0.55
17664/17665 ( 4500/4501 hex )
17666/17667 ( 4502/4503 hex )
17668/17669 ( 4504/4505 hex )
17670/17671 ( 4506/4507 hex )
17672/17673 ( 4508/4509 hex )
17674/17675 ( 450A/450B hex )
17676/17677 ( 450C/450D hex )
17678/17679 ( 450E/450F hex )
17680/17681 ( 4510/4511 hex )
17682/17683 ( 4512/4513 hex )
17684/17685 ( 4514/4515 hex )
17686/17687 ( 4516/4517 hex )
17688/17689 ( 4518/4519 hex )
17690/17691 ( 451A/451B hex )
17692/17693 ( 451C/451D hex )
17694/17695 ( 451E/451F hex )
32-bit unsigned
Touchscreen Menu Path:
none
