Chapter 3: Configuration and Parameters
Page 3–33Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
parameTer deTails – “advanCed” menu of parameTers (ConTinued)
P6.2 – iERS Rate Type:
Description: Read/Write
Determines the rate at which the load is regulated during the energy saving mode.
• Increase if the applications shows signs of instability.
• Reduce to increase the speed of response.
Range: Modbus Decimal Value: Default:
0% – 100% linear scale ( 1 = 0.006104 % )
0% – 100% = (0 – 16384)
x% / 0.006104% = Modbus dec. value
EX: Modbus value of 5250 = 32.05%
25%
Modbus Address: Modbus Format:
21184 ( 52C0 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → iERS → iERS Rate
P6.3 – iERS Level Type:
Description: Read/Write
Determines the maximum energy saving potential.
• Reduce if the application shows signs of instability.
• The amount of energy that can be saved may fall as the “iERS Level” is reduced.
Range: Modbus Decimal Value: Default:
0% – 100% linear scale ( 1 = 0.006104 % ) 100%
Modbus Address: Modbus Format:
21376 ( 5380 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → iERS → iERS Level
P6.4 – Fixed Voltage (Level) Type:
Description: Read/Write
User settable voltage level for power calculations.
• If required, can be used to improve accuracy of power calculations.
• This voltage level will be displayed on the “Monitor” screen as Vrms (Approx) if Fixed Voltage is
turned on.
Range: Modbus Decimal Value: Default:
100V – 500V linear scale ( 1 = 1 V ) 100V
Modbus Address: Modbus Format:
35200 ( 8980 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → iERS → Fixed Voltage (Level)
