Chapter 3: Configuration and Parameters
parameTer deTails – “advanCed” menu of parameTers (ConTinued)
P8.3 – Overload Trip Hold. Reg. Type:
Description: Read/Write
The overload is an electronic equivalent to a thermal overload.
(See Overload parameter address 33408 for more information about Overload.)
Range: Modbus Decimal Value: Default (decimal):
• Off : The SR55 will continue to operate regardless of motor
current level.
• On : The SR55 will trip when the “Overload” capacity exceeds
the motor current level chosen in Overload Level and Trip
Class parameters.
• 0
• 1 • On (1)
Modbus Address: Modbus Format:
53792 ( D220 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → Trip Settings → Overload Trip
(also Home → Advanced → Motor Protection → Overload Settings → Overload Trip)
P8.4 – Low Current Trip Hold. Reg. Type:
Description: Read/Write
This can be used to detect if the motor is running lightly loaded.
Range: Modbus Decimal Value: Default (decimal):
• Off : The SR55 will continue to operate regardless of motor
current.
• On : The SR55 will trip. This feature is not active during soft
start and soft stop.
• 0
• 1
• Off (0)
Modbus Address: Modbus Format:
53787 ( D21B hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → Trip Settings → Low Current Trip
(also Home → Advanced → Motor Protection → Low Current Settings → Low Current Trip)
P8.5 – Start Current Limit Trip Hold. Reg. Type:
Description: Read/Write
Selects between trip or continue if the start current limit has been active for too long.
Range: Modbus Decimal Value: Default (decimal):
• Off : The start will continue regardless of the motor current
level.
• On : The SR55 will trip. This trip is constrained by the Start
Current Limit Level and the Start Current Limit Time.
• 0
• 1 • On (1)
Modbus Address: Modbus Format:
53790 ( D21E hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → Trip Settings → Start Current Limit Trip
(Home → Advanced → Start Settings → Start Current Limit → Start Current Limit Trip)
