parameTer deTails – “advanCed” menu of parameTers (ConTinued)
P8.6 – Stop Current Limit Trip Hold. Reg. Type:
Description: Read/Write
Selects between trip or continue if the stop current limit has been active for too long.
Range: Modbus Decimal Value: Default (decimal):
• Off : The stop will continue regardless of the motor current
level.
• On : The SR55 will trip. This trip is constrained by the Stop
Current Limit Level and the Stop Current Limit Time.
• 0
• 1
• Off (0)
Modbus Address: Modbus Format:
53791 ( D21F hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → Trip Settings → Stop Current Limit Trip
(also Home → Advanced → Stop Settings → Stop Current Limit → Stop Current Limit Trip)
P8.7 – PTC Motor Thermistor Trip Hold. Reg. Type:
Description: Read/Write
A single PTC motor thermistor or set of PTC motor thermistors can be connected to the PTC
terminals.
Range: Modbus Decimal Value: Default (decimal):
• Off : The SR55 will continue to operate.
• On : The SR55 will trip if the motor thermistor exceeds its
response temperature, or the PTC input is open circuit (> 4kΩ).
• 0
• 1
• Off (0)
Modbus Address: Modbus Format:
53794 ( D222 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → Trip Settings → PTC Motor Thermistor Trip
(also Home → I/O → PTC Motor Thermistor Trip)
P8.8 – L1-L2-L3 Trip Hold. Reg. Type:
Description: Read/Write
Determines if supply phase sequence is incorrect for motor rotation.
Range: Modbus Decimal Value: Default (decimal):
• Off : The SR55 will continue to operate normally.
• On : Trips if the phase sequence is L1, L2, L3.
• 0
• 1
• Off (0)
Modbus Address: Modbus Format:
53808 ( D230 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → Trip Settings → L1-L2-L3 Trip
P8.9 – L1-L3-L2 Trip Hold. Reg. Type:
Description: Read/Write
Determines if supply phase sequence is incorrect for motor rotation.
Range: Modbus Decimal Value: Default (decimal):
• Off : The SR55 will continue to operate normally.
• On : Trips if the phase sequence is L1, L3, L2.
• 0
• 1
• Off (0)
Modbus Address: Modbus Format:
53807 ( D22F hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Advanced → Trip Settings → L1-L3-L2 Trip
